OPTIONAL “BASIC SET” OF UNDERWATER MASSAGE SYSTEM/EQUIPMENT WITH PERMANENTLY ATTACHED HOSE/NOZZLE
(CAN NOT BE DISCONNECTED/DETACHED BETWEEN TREATMENTS)
NOTE: UWM EQUIPMENT IS FULLY INSTALLED ON THE TUB DURING PRODUCTION.
# PART# PART DESCRIPTION “BASIC SET #1” “BASIC SET #2” “BS” #1 “BS” #2

“BS” #1 “BS” #2

1 FLH-9 PERMANENTLY CONNECTED UNDERWATER PRESSURE UP TO NOTE: INCLUDES
PERMANENTLY MASSAGE SPECIAL GRADE FLEX HOSE WITH BRASS 45PSI/3ATM ADDITIONAL PRESSURE
CONNECTED CHROME PLATED FITTINGS. BOOSTING PUMP
CREATES WATER
PRESSURE UP TO
2 N-04 SPECIAL UNDERWATER POINTED MASSAGE PLASTIC 90 PSI/6 ATM
NOZZLE.
#4

3 HNH-CP CHROME PLATED HOSE/NOZZLE HOLDER.

4 T-PR-G PRESSURE / TEMPERATURE GAUGE INTEGRATED
INTO A SPECIAL HOUSING WITH CONNECTION
FITTINGS.

5 VLV-3/4 UNDERWATER MASSAGE SYSTEM BRASS CHROME
PLATED CONTROL VALVE.

6 UMSCB UMSCB RMS® ELECTRONIC BOOSTER PUMP
CONTROL BOX WITH TWO LEVELS OF SAFETY
PROTECTION SYSTEM. INCLUDES:
2. WATER LEVEL SENSOR.
3. PRESSURE SENSOR WITH A SPECIAL IN LINE
INSTALLATION FITTING.
4. AUDIO ALARM SYSTEM.
5. PNEUMATIC ON/OFF BUTTON.
6. UNIVERSAL SET OF HOOK-UP CABLES FOR BOOSTING
PUMP CONNECTION.
NOTE: UMSCB PROTECTS BOOSTER PUMP FROM DRY RUN AND
OVER-PRESSURE. CREATES SIMPLE, SAFE, USER-FRIENDLY
SYSTEM OPERATION.
7 WPB-01 ADDITIONAL PRESSURE BOOSTING PUMP FOR “BS” #8
ONLY
