DOUBLE FLARING TOOL

For the flaring of brake and clutch pipes
on all passenger cars and trucks.

• Can be used for copper, steel and aluminium
pipes.
• For bordering D-E-F to DIN 74 234.
• The various mandrel sizes are ad justed
by turning the revolving head. No time
consuming changing of the mandrels.
• The mandrel is automatically removed from
the bordering by means of an eccentric lever.
Description Art. No. Pack Qty.
Double Flaring
Tool Kit 0714 91 02 1

Contents of Kit
Description Art. No. Pack
Qty.
Clamping Jaws
4.75 mm DIN convex 0714 91 04
Clamping Jaws 6 mm 0714 91 05
Clamping Jaws 8 mm 0714 91 06
Clamping Jaws 10 mm 0714 91 07
Mandrel O. P. 1
Internal and External Pipe Milling Cutter Mandrels Clamping Jaws 4.75 mm DIN convex 0714 91 08
Mandrel O. P. 1 6 mm 0714 91 10 1
• For time saving and Mandrel O. P. 1 8 mm 0714 91 11
easy de-burring of Mandrel O. P. 1
pipe ends. 10 mm 0714 91 12
Mandrel O. P. 2 0714 91 13
Pipe Milling Cutter. 3/16” + 6 mm
For pipe Dia. mm Art. No. Pack Qty. Mandrel O. P. 2 0714 91 14
3 – 42 0714 91 20 1 8 mm + 10 mm

Application Table for Mandrels and Clamping Jaws
Type Suit Tube Mandrel Clamping Jaw
Outer Ø Art. No. Art. No. Additional Tools
SAE (convex) 6 mm 0714 91 10 0714 91 05 Description Art. No. Pack
DIN edge E 8 mm 0714 91 11 0714 91 06 Qty.
(O.P.1) 10 mm 0714 91 12 0714 91 07 Mandrel OP1 0714 91 10
1/4”+6mm
DIN (convex) Mandrel OP1 0714 91 161
DIN edge F (O.P.1) 1/2”+12mm
4.75 mm 0714 91 08 0714 91 04 Mandrel OP1 3/8” 0714 91 171
• Exclusively for union nuts Mandrel OP1 5/16” 0714 91 181
with male metric thread
Mandrel OP2 1
SAE/DIN (double) 3/16” 1/2”+12mm 0714 91 203
DIN edge E 4.75 mm 0714 91 13 - Clamping jaws 12mm 0714 91 23
0714 91 10
(O.P.2)
6 mm
0714 91 24
Clamping jaws 1/4”
AUS. pub. 12/16 © 8 mm 0714 91 13 0714 91 05 Clamping jaws 5/16” 0714 91 25
0714 91 14
0714 91 06
0714 91 26
Clamping jaws 3/8”
10 mm
0714 91 14
0714 91 27
Clamping jaws 1/2”
0714 91 07
