ASSY 3.0 A2
®

Application:
The ASSY 3.0 A2 of corrosion-resistant,
®
austenitic stainless steel is designed especially
for applications outdoors, in damp rooms and in
salty atmospheres.

Tip:
Ring thread → Minimal splitting effect, especially
when screwing in near the edge

Thread:
Countersunk head* Asymmetrical coarse thread for short screw-in

d in l in dk in b in Bit colour w/shaft Pack Qty. times.
A2
mm mm mm mm Art. No. Head:
60 37 0180 106 60 Milling pockets for clean countersinking.
80 50 0180 106 80 AW drive.
®
6.0 100 12.0 60 AW ® 30 0180 106 100 100
120 70 0180 106 120 Material:
140 70 0180 106 140 Corrosion-resistant, austenitic stainless steel A2
(1.4301; 1.4567).

Note:
Pre-drilling to the core diameter in solid hard
woods. ASSY 3.0 A2 are conditionally
®
resistant to acid and are not suitable for use in
atmospheres containing chlorine gas.

The range of applications of the various stainless steels is contained in We therefore recommend only using austenitic stainless steels for outdoor
the following table of the ISER (German Information Office for Rustproof applications while taking the environmental conditions into account. The
Stainless Steel, Information Leaflet 828). Rustproof stainless steels stainless steel A4 is especially suitable for use in an industrial atmosphere
(e.g. Material No. 1.4016) are recommended there for use and for use near the sea.
in the atmospheric area only for use in a rural environment,
and here as well only with great restrictions.
Steel Type Short Name Environment
Rural Urban Industry Near sea
Material No. N M H N M H N M H N M H
X1NiCrMoCu25-20-5 1.4539 Würth HCR x x x x x x x x + x x +
X5CrNiMo17-12-2 1.4401/1.4578 Würth A4 x x x x + + + + (+) + + (+)
X5Cr-Ni18-10 1.4301/1.4567 Würth A2 + + + + + (+) (+) (+) – + (+) –
X6Cr17 1.4016 Many competitors (+) (+) (+) (+) – – (+) – – – – –

Stainless steels for various ambient conditions (www.edelstahl-rostfrei.de,
Information Leaflet 828)
N = Lowest corrosion loading within the respective environment, + = Probably the best choice of materials with regard to corrosion
characterized, forexample, by low temperatures and low humidity resistance and costs
M = Medium corrosion loading within the respective environment (+) = Sufficient behaviour, provided certain precautionary measures are
H = Higher corrosion loading within the respective environment, e.g. due taken. Smooth surface finishes and regular cleaning are especially
to continuously high humidity, high ambient temperatures, especially important
aggressive air pollution – = Probably heavy corrosion
x = Basically meets the requirements, however less expensive steels could
also be sufficient
AUS. pub. 06/15 © ASSY 3.0 particle board screws are optimized for use in wooden materials. When used in plastic

®
anchors, a reduction of the load-bearing capacity is possible. For this reason, we recommend only using
screws without optimized thread tips.
06 3731
