Page 812 - Wurth Total Catalogue

TEMPORARY DOWNPIPE

Protects house facades against soiling
and structural damage.

Reliable protection of the facade.
No costs for eliminating soiling and structural
damage.

Cost-effective.
Less expensive than temporary plastic pipes.

Simple handling.
• Fast and easy to install and remove.
• Practical roll-off box simplifies application.

Universal use.
Downpipe replacement can be used for all pipes
up to 150 mm diameter.

Instructions for use:
The roll-off box is placed on the floor and the
downpipe replacement is pulled upward towards
the drain connection piece. The downpipe
replacement is fixed in place using cable ties or
adhesive tapes. Fastening in the centre and at the
lower end is also advisable.

Applications: Roll Diameter Art. No. P. Qty.
Downpipe replacement is used when the drain Length
pipe is temporarily removed, e.g. for painting or 150 m 200 mm 0818 070 150 1
plumbing work. The rain water then does not flow
along the facade, but instead through the film
hose.

Technical Data:
Film thickness: 0.14 mm
Film material: Polyethylene (recyclable, neutral to
ground water). Partner Products:
AUS. pub. 08/17 © Cable Ties

Adhesive Tapes
Knife

09 1581
