Page 24 - Arthroscopic Knot Tying: An Instruction Manual
P. 24

P.17
                   Optimal Configuration of Half Hitches




                   Half hitches can be thrown in the same direction (two successive overhand hitches) or can be thrown in
                   opposite directions (an overhand hitch followed by an underhand hitch). Half hitches can also be tied on
                   opposite  posts.  Tera  and  Aberg  (37  )  developed  a  nomenclature  for  describing  flat  knots.  This  was
                   modified by Trimbos (38 ) to describe the configuration of sliding knots (Table 1 ).



                                  TABLE 1 Nomenclature for Describing Sliding Knots (38 )

                       Symbol             Definition                           Example
                         S        Sliding Throw                 Single half hitch
                                  Identical throw around        Successive overhand loops around the same
                         =        same post                     post
                                  Nonidentical throw around     Overhand loop followed by an underhand
                         X        same post                     loop on the same post
                                  Post switching between        Overhand loop followed by post switching
                         //       throws                        and an overhand loop
