Anchors Systems

Setting tool (HMU) HMU-ST
Key applications and advantages Technical data
■ Ensures fast and reliable setting of the Dispenser, setting Anchor testers and ac-
HMU undercut anchor tool, accessory, cessories, Setting tools
tester type

Ordering designation Connection end Package contents Sales pack Item number
quantity
HMU-ST M16 TE-C 1x Setting tool HMU-ST M16 1 pc 2036378

Undercut tool (HMU) TE-Y-HMU-UC

Key applications and advantages Technical data
■ Produces consistent, high-quality Dispenser, setting Anchor testers and
undercuts tool, accessory, accessories, Undercut
tools
tester type

Ordering designation Package contents Sales pack Item number
quantity
HMU-UC-CB 22-M16 1 pc 2036370
HMU-UC-CB 22-M16 DIA 1 pc 2036371
TE-C-HMU-UC 22-M16 1x Undercut tool TE-C HMU-UC 22,5 1 pc 2036249 Anchors

Dynamic / filling set for anchors with seismic and
fatigue approval (CS) HDA/HVZ

Ordering designation Outer ring bolt diameter Package contents Sales pack Item number
quantity
M10 42 mm 0.5x Hexagon nut M10 2 pc 369201
M16 52 mm 0.5x Hexagon nut M16 2 pc 369203
M20 60 mm 0.5x Hexagon nut M20 2 pc 369204
