Firestop and Fire Protection Systems

Firestop collar CP 643 N Firestop collar CP 644
Technical data Approvals Technical data Approvals
Expansion temper- 250 °C FM (Factory Mutual) Expansion temper- 210 °C DIBt CP 644 Kabelabschottung S90
ature (approx.) Approvals and test reports may apply to selected ature (approx.) Elektroleerrohre ABZ: Z-19.15
Expansion ratio 1:17 products only. Please refer to the documents for Expansion ratio 1:17 1781
(unrestricted, up to) details. (unrestricted, up to) CP644 Rohrabschottung R90
Application temper- -5 - 50 °C Application temper- -5 - 50 °C ABZ: Z-19 17-1577
ature range ature range Penetration C-AJ-2109
Building material B2 Building material B2 C-AJ-2283
Key applications and advantages C-AJ-2284
class (according to Key applications and advantages class (according to
■ Plastic pipes with diameters from 32 - DIN 4102) ■ Sealing flammable pipes from 32 mm DIN 4102) C-AJ-2285
170 mm W-L-2078
Base materials Concrete, Drywall, to 250 mm in diameter in penetrations Base materials Concrete, Drywall,
■ Pipes with acoustic insulation Masonry through fire compartment walls and Masonry Approvals and test reports may apply to selected
■ Suitable for PVC, PE and HDPE pipes LEED VOC 7.6 g/l floors LEED VOC 7.6 g/l products only. Please refer to the documents for
details.
■ Ready-to-use product ■ PVC, HDPE, PP and ABS pipes
■ Latch mechanism for quick and easy ■ Pipes with acoustic insulation
closure ■ Ready-to-use firestop collar with a
galvanized steel housing
■ Latch mechanism for quick and easy
closure
Ordering designation Outside diameter Sales pack Item number
quantity
CP 643-50/1.5” N 67 mm 1 pc 304325
CP 643-63/2” N 82 mm 1 pc 304326
CP 643-90/3” N 116 mm 1 pc 304328
CP 643-110/4” N 146 mm 1 pc 304329
CP 643-125/5” N 166 mm 1 pc 304330
CP 643-160/6” N 236 mm 1 pc 304331 Ordering designation Outside diameter Sales pack Item number
quantity
CP 644-50/1.5” 67 mm 1 pc 304332
CP 644-63/2” 82 mm 1 pc 304333
CP 644-75/2.5” 102 mm 1 pc 304334
CP 644-90/3” 117 mm 1 pc 304335
CP 644-110/4” 146 mm 1 pc 304336
CP 644-125/5” 166 mm 1 pc 304337
CP 644-180/7” 228 mm 1 pc 304339
CP 644-160/6” 236 mm 1 pc 304338
CP 644-200/8” US 257 mm 1 pc 304341
CP 644-225/9” 289 mm 1 pc 304342
CP 644-250/10” 319 mm 1 pc 304343
Firestop and Firestop and Fire Protection Fire Protection Systems Systems

336 Visit the website for more information on products and services. www.hilti.group 337
