Installation Systems

Hot-dip galvanized threaded rod AM Hot-dip galvanized hexagon nut
Technical data Technical data
Material Steel grade 4.8 Material Steel grade 8
composition composition
Surface finish Hot-dip galvanized Surface finish Hot-dip galvanized -
DIN EN ISO 10684

Ordering designation Thread - M Length - L Weight Sales pack Item number
quantity
AM10x1000-F 4.8 M10 1000 mm 435 g 20 pc 304773
AM10x2000-F 4.8 M10 2000 mm 950 g 20 pc 414784 Ordering designation Thread - M Height - H Wrench size - W Weight Sales pack Item number
quantity
AM12x1000-F 4.8 M12 1000 mm 687 g 15 pc 304774
M8-F M8 7 mm 13 mm 5 g 100 pc 2142984
AM12x2000-F 4.8 M12 2000 mm 1433 g 15 pc 304775 /
M10-F M10 8 mm 17 mm 11 g 100 pc 2142985
AM16x1000-F 4.8 M16 1000 mm 1320 g 5 pc 304776 0
0 M12-F M12 10 mm 19 mm 16 g 100 pc 2142986
AM16x2000-F 4.8 M16 2000 mm 2622 g 5 pc 304777
+
AM20x1000-F 4.8 M20 1000 mm 2066 g 5 pc 304778 M16-F M16 13 mm 24 mm 30 g 50 pc 2142987 :
AM20x2000-F 4.8 M20 2000 mm 4109 g 5 pc 304779
M20-F M20 16 mm 30 mm 55 g 50 pc 304768
Hot-dip galvanized flat washer DIN 125 Prevailing torque hexagon nut HDG M10-SL-F

Technical data Key applications and advantages Technical data
Material Steel - DIN EN ISO 7089 ■ Self-locking function through the nut Material Steel grade 8
composition insert composition
Surface finish Hot-dip galvanized Surface finish Hot-dip galvanized

Ordering designation Inside diameter - DI Outside diameter - DA Cross section thickness - s Weight Sales pack Item number
quantity
A 8,4/16-F 8.4 mm 16 mm 1.6 mm 2 g 100 pc 2142951
',
A 10,5/20-F 10.5 mm 20 mm 2 mm 3 g 100 pc 2142952
6
A 13/24-F 13 mm 24 mm 2.5 mm 6 g 100 pc 2142953 Ordering designation Tightening torque Weight Sales pack Item number
'$ quantity
A 17/30-F 17 mm 30 mm 3 mm 10 g 100 pc 2142954 M10-SL-F 40 Nm 16 g 100 pc 2063245

0
Flat washer similar to ISO 7089 (HDG) Hot-dip galvanized hexagon bolt

Technical data Technical data
Material Steel Material Steel grade 8.8
composition composition
Installation Installation Systems Systems
Surface finish Hot-dip galvanized Surface finish Hot-dip galvanized

Ordering designation Inside diameter - DI Outside diameter - DA Cross section thickness - s Weight Sales pack Item number
quantity
A 10,5/28-F 10.5 mm 28 mm 2 mm 8 g 100 pc 2063247 ',
6
'$

434 Visit the local website for more information on products and services www.hilti.group 435
