P. 268
V2200/H Series
Dimensions O.A O.A O.A SEAT SEAT SEAT
LENGTH DEPTH HEIGHT LENGTH DEPTH HEIGHT
V2201/V2201H Double Reclining Sofa 87" 40" 41" 69" 21" 20"
V220018 Console w/Cup Holders 13" 40" 41"
V220020 Super Wedge 74" 40" 41"
V220039 Armless Chair 24" 40" 41" 23" 21" 20"
V220032/V22032H Min Prox Recliner 39" 40" 41" 21" 21" 20"
V220052/V22052H Rocker Recliner 39" 40" 41" 21" 21" 20"
V220054/V22054H Armless Recliner 24" 40" 41" 23" 21" 20"
V220057/V22057H RAF Recl Chair 32" 40" 41" 23" 21" 20" H = Power Tilt Headrest
V220058/V22058H LAF Recl Chair 32" 40" 41" 23" 21" 20"
V220085/V22085H Double Reclining Loveseat Console 77" 40" 41" 46" 21" 20"
June 21
Features
Cushions/Backs/Removable Sinuous Wire
Cushions/Back/Semi-Attached Polyester fiber fill - Zipper Access
Cushions/Seat 2.0 lb high resiliency block foam with polyester fiber wrap
Locking Bracket Standard on all modular pieces
Legs/Plastic -18, -20, -39: 3" (Screw-In)
-01, -32, -52, -54, -57/-58, -85: Integral part
of frame with glide
Power & Battery Pack Available
Removable Backs Standard
Seat Construction Sinuous Wire
Seating/Tight Standard
