EX2300 Ethernet Switch
• 802.1X with VoIP VLAN support • Out-of-band management: Serial, 10/100BASE-T Ethernet
• 802.1X dynamic ACL based on RADIUS attributes • ASCII configuration
• 802.1X Supported EAP types: Message Digest 5 (MD5), • Rescue configuration
Transport Layer Security (TLS), Tunneled Transport Layer • Configuration rollback
Security (TTLS), Protected Extensible Authentication Protocol • Image rollback
(PEAP) • Simple Network Management Protocol (SNMP): v1, v2c, v3
• IPv6 RA Guard • Remote monitoring (RMON) (RFC 2819) Groups 1, 2, 3, 9
• IPv6 Neighbor Discovery Inspection • Network Time Protocol (NTP)
• Captive Portal • DHCP server
• Static MAC authentication • DHCP client and DHCP proxy
• MAC-RADIUS • DHCP relay and helper
• Control plane DoS protection • RADIUS authentication
• Fallback authentication • TACACS+ authentication
• Trusted Network Connect (TNC) certified • SSHv2
• Secure copy
High Availability
• HTTP/HTTPs
• Link aggregation • DNS resolver
• 802.3ad (LACP) support: • System log logging
- Number of LAGs supported: 128 • Temperature sensor
- Maximum number of ports per LAG: 8 • Configuration backup via FTP/secure copy
• Tagged ports support in LAG • Interface range
• Uplink Failure Detection
Supported RFCs
Quality of Service (QoS)
• RFC 768 UDP
• Layer 2 QoS • RFC 783 Trivial File Transfer Protocol (TFTP)
• Layer 3 QoS • RFC 791 IP
• Ingress policing: one-rate two-color; two-rate three-color • RFC 792 Internet Control Message Protocol (ICMP)
markers • RFC 793 TCP
• Hardware queues per port: 8 • RFC 826 ARP
• Scheduling methods (egress): Strict Priority (SP), shapeddeficit • RFC 854 Telnet client and server
weighted round-robin (SDWRR) • RFC 894 IP over Ethernet
• 802.1p, DSCP /IP precedence trust and marking • RFC 903 Reverse ARP (RARP)
• L2-L4 classification criteria: Interface, MAC address, EtherType, • RFC 906 Bootstrap Loading using TFTP
802.1p, VLAN, IP address, DSCP/IP precedence, TCP/UDP • RFC 951, 1542 BootP
port numbers • RFC 1027 Proxy ARP
• Congestion avoidance capabilities: Tail drop and WRED
• RFC 1058 RIP v1
Multicast • RFC 1122 Requirements for Internet Hosts
• IGMP snooping entries: 2,000 • RFC 1256 IPv4 ICMP Router Discovery (IRDP)
• IGMP: v1, v2, v3 • RFC 1492 TACACS+
• IGMP snooping • RFC 1519 Classless Interdomain Routing (CIDR)
• PIM-SM, PIM-SSM, PIM-DM • RFC 1591 Domain Name System (DNS)
• MLD snooping • RFC 1812 Requirements for IP Version 4 routers
• RFC 2030 Simple Network Time Protocol (SNTP)
Services and Manageability
• RFC 2068 HTTP/1.1
• Juniper Mist Wired Assurance • RFC 2131 BOOTP/DHCP relay agent and DHCP server
• Junos OS CLI • RFC 2138 RADIUS Authentication
• Junos Web interface (J-Web) • RFC 2139 RADIUS Accounting
• Junos Space Management Applications • RFC 2267 Network Ingress Filtering
• Junos Space Network Director • RFC 2453 RIP v2
