Using Multiple Matrices for Esthetic Enhancement:
A Case Presentation
Author: Arthur R. Volker, DDS, MSc, MSEd, FAGD
Introduction:
In operative dentistry, the purpose of a matrix is to act as a shape former and facilitate the placement of a restorative material. Matrices
are often specific to a particular surface of a tooth, such as the interproximal or cervical. To maximize results, matrices can be combined.
This article demonstrates a clinical case whereby a Bioclear matrix was combined with a Mylar strip to restore a maxillary lateral incisor.
Case Presentation:
The patient was a 37-year-old female in good overall health. Approximately seven years ago, direct polychromatic composite veneers were
placed on #7-10. Following a five-year absence from the office, the patient returned to address a fracture at #10. To restore the interproximal
area, a Bioclear matrix (BT, Bioclear) was used. To veneer the remainder of the tooth, a standard Mylar strip was tucked into the sulcular
area and a microfilled composite (Renamel, Cosmedent) was injection-molded and shaped to complete the restoration.
Figure 1. Pre-operative presentation. Figure 2. Removing remaining composite resin and caries.
Figure 3. Calculus and caries noted on mesial surface. Figure 4. Removal of mesial caries.
Figure 5. Preparation completed. Figure 6. An air abrasion unit (Bioclear Blaster, Bioclear) was
used to remove any remaining biofilm.
