BUCKET CONVEYOR
QUESTIONNAIRE

Client Name _________________________________________________________________________

Address ____________________________________________________________________________

Contact Name ___________________________________________ Position __________________

Phone _______________________________________ Fax _________________________________

E-Mail _______________________________________ Date _________________________________

NATURE OF MATERIAL
Product Name or Description _______________________________________ Wt./Cu. Ft. _________

Particle Size (if lumpy, state max. size; if dusty, how many microns) ___________________________
Is product Free-flowing? Abrasive? Corrosive? Deliquescent? Hygroscopic? Sticky?
Is product Hot? Cold? Temp _____________ Wet? Dusty? Fragile? Static?
Is any fat or oil present? Yes No (If possible, send a small sample in an airtight container for inspection.)
Can these conditions ever vary? Yes No

THROUGHPUT REQUIREMENTS
State type of feed, i.e. controlled or flood feed from bin or hopper _____________________________
What is the equipment feeding and what is expected of it? ______________________________________
If feeding is continuous, state rate per hour: Min. __________ Max. _________ Hrs. usage/day_____
If feeding is intermittent, state max. rate per hour: _________ and operation cycle ________________
Number of infeed positions __________________ Number of discharge positions_________________

CONSTRUCTION MATERIALS AND FINISH
Case construction Carbon Steel Stainless Steel If stainless steel, indicate type: ____________
Bucket type: Polypropylene Carbon steel Stainless Steel Other ____________________
Chain type: Carbon steel Stainless Steel Polyacetal Other ______________________
Construction type: Folded Tubular Other _________________________________________
Enclosure: Open (will be enclosed to 7'-0" elevation for safety) Weather proof Explosion proof
Fully enclosed (indicate cover material): Carbon steel Stainless steel Lexan
Specify finish: Steel-It® Enamel Bare Polished Other_________________________
Are roof or floor supports required? Yes No (If yes, indicate height requirements) ____________

DRIVE
Electrical supply details: Voltage _______________ Phase _______________ Hz_______________
Enclosure type: Drip proof Totally enclosed Washdown Explosion proof NEMA ____

Are controls required? Yes No
Site address, if different from above: ____________________________________________________
___________________________________________________________________________________

Please fax to Gough Econ, Inc. 704-392-8706, attn: Sales Department
