BULK MATERIAL HANDLING SOLUTIONS

E Ec co on n- -O O- -L Li if ft t B Bu uc ck ke et t E El le ev va at to or rs s

Typical Engineering Data

C Co on ns st tr ru uc ct ti io on n: : S Sp pr ro oc ck ke et t & & S Sh ha af ft t D De es si ig gn n: :

Tubular, open, folded construction or totally enclosed Easily removed sprockets made from steel
designs available. (for steel chains) or a polymeric compound
(for plastic chains).
Construction Materials: 11-gauge folded steel side panels
with 14-gauge steel, stainless steel, or lexan cover panels. S Sp pr ro oc ck ke et t/ /s sh ha af ft t b be ea ar ri in ng g: :

All elevators are covered up to 7’-0” for safety purposes. Sealed flange bearing

L Lu ub br ri ic ca at ti io on n: :
B Bu uc ck ke et t D De es si ig gn n: :
Lubrication required on CS & SS chains
(Lubrication used depends on application)
From 6” wide to 48” wide on 9” pitch No lubrication required on plastic chain

Construction Materials: Carbon steel, stainless steel or
polypropylene, as required T Te em mp pe er ra at tu ur re e: :

Tipping mechanism: Individually replaceable tipping -22 °F (-30 °C) up to 230 °F (110 °C)
sprockets allow 360º rotation 120 °F highest recommended temperature for
plastic buckets
Mild steel and stainless steel allow higher
temperatures

F Fi in ni is sh h: :
Steel It  air dry polyurethane

C Ch ha ai in n D De es si ig gn n: : I In n- -F Fe ee ed d O Op pt ti io on ns s: :
Controlled in-feed recommended
Pro-coated 3” pitch
D Di is sc ch ha ar rg ge e O Op pt ti io on ns s: :
Construction Materials: Acetyl plastic, carbon steel or “Over the end” discharge.
stainless steel Single or multiple discharge(s) anywhere in
circuit

D Dr ri iv ve es s: :
Drive HP, voltage, etc. dependent on
application. Motor drives into a gearbox,
which is then transferred via transmission
chain and sprockets. A torque limiter
provides protection to elevator main chains
and components.

T To ou ug gh h, , G Ge en nt tl le e, , C Cl le ea an n
Gough Econ, Inc.
P.O. Box 668583, Charlotte, NC 28266-8583
Phone: 800.264-6844 Fax: 704.392.8706
E-Mail: sales@goughecon.com
Form: EconOLift .doc Rev 1
Website: www.goughecon.com
