SECTION 6 MATERIAL UNLOADING
Bag Dump Hopper

BAG DUMP HOPPER
• Available with vent stub to connect to your
existing dust collection system
• Available with self-contained bin vent with
exhaust fan for locally induced dust collection
• Stainless steel construction
• Epoxy-coated carbon steel and food-grade
construction available upon request
• Standard discharge flange configured for
installation of Smoot rotary valve; alternative
discharge flange connections are available
• NEMA 4 classified electrical components standard;
NEMA 7/9 components also are available
• Available with or without working platform

EXHAUST FAN

CONNECTS TO CUSTOMER DUST COLLECTION
DUST COLLECTOR

HINGED DOOR HANDLE
BAG SHELF (OPTIONAL)

PLATFORM WITH CORREGATE
FLOOR PLATE (OPTIONAL)

SIDE VIEW SHOWING FRONT VIEW SHOWING
VENT LINE STUB OPTIONAL PULSE JET FILTER
