CUP FILLERS

The SC/Series cup filler can accurately dispense free-flow products such as rice, popcorn, pecans,
seeds, candy and more. Fill weights from .25oz to 15lbs can be achieved at speeds up to 120 per
minute. Easily removable volume cups and servo position control are standard features on this line.
SPECIFICATION SUMMARY:
Construction Control Features • Sanitary design
• Painted aluminum base • Alpha-numeric product naming • 316 contact parts
• Anodized aluminum • Containers per minute readout • Conveyor with indexing/automation
• Stainless steel contact parts • Individual control of all settings • Integration with OEM (VFFS etc..)
Power • User / maintenance / supervisor log in • Vibratory pan in feed
• 220V /1ph/60hz (standard other Options
voltages available) • Single or dual discharge
Controls • Servo cup position control
• 7.00” color touch screen • Hopper cover
• PLC controlled • Product level sensor
• 100 product memory • Washdown

CSC/400
