Auger Fillers
VERTICAL FORM FILL & SEAL
Net Weigh Fillers

The All-Fill A/3400 VFFS is built to form and fill large bags sized from 8” x 14” up to 18” x 36” at
speeds up to 25 cycles per minute with a pneumatic jaw closure and provides accurate, efficient
packaging of pillow, gusseted, hole-punch, and custom containers. With weight capacities as Cup Fillers
small as 5 pounds up to as much as 50 pounds, the A/3400 features color touch screen controls to
provide easy setup, testing, and operation from self-explanatory screens and selections. Multiple
routines stored in memory can be used for each product, filling amount, or type. Piston Fillers
BAG STYLES:
Doy-Style
Stand-up Bag Hole Punch Pillow Bag Gusset Bag
Checkweighers
SPECIFICATION SUMMARY:
Vertical Form Fill & Seal
Package Sizes 12” x 14” to 18” x 36”
Package Weights Forms and fills 5lbs. to 50 lbs.
Production Rates Up to 20 cycles per minute
Tool Size Changeover Tool-less changeover
Machine Dimensions 73” x 101” x 106” Labelers
Roll Diameter 24”
Electrical 208/240V, Single Phase, 50/60 Hz., 25A
Pneumatic Up to 60 SCFM @ 70 psi Unscramblers
Component Types Common, off-the-shelf components
A/3400 Routine Storage PLC control stores 50 routines with a 7” widescreen color HMI
Vertical Form Fill & Seal with
Machine Accessories
Integrated Auger Filler Environment 50°F (10°C) to 90°F (32°C) up to 95% relative humidity
(Formerly Avatar)
