NADISO  BIOSAFETY COVID SYSTEM (NBCS)
                         ®
               NBCS provides protection for user, product, and environment specialty from covid 19 virus and
               other bioparticulate hazards. The work area is creating a negative pressure airflow into the
               cabinet, then the air exhausted  to the scrubber treatment anti covid system. This NBCS are
               designed  for  the  safe  handling  of  virus covid  19    and  other  hazardous  virus  in  Laboratory,
               Hospital, Puskesmas, Clinic, Pharmacy and others.

               The work area is bathed with a HEPA-filtered unidirectional (laminar) flow ISO 5/Class 100 air
               to protect the product. This filter removes organisms and particulates 0.3 micron in size with an
               efficiency of 99.99%. This is Class II, Type B2 Biological Safety Cabinet is a 100% total exhaust
               unit, ducted (vented) to the Scrubber Anti Covid System until release to the environment with
               clean and safe.

                       •  Work area surrounded by negative pressure, it can ensure maximum safety in work
                          area
                       •  Ergonomic  front  panel  is  concave  permitting  operator  to  lean  into  work  area,
                          enhancing user comfort.
                       •  Most accessories are standard. No need to pay more, save your money.
                       •  All functions can be realized with it, making the operation much easier and more
                          convenient
                       •  Integrated with Scrubber system
                       •  Integrated with smart lab nadiso versi 01. The data transmitted using 2 pcs Bar Code
                          /QR Code Scanner



               Specifications :

                       •  Motorized Front Window, max ppening 400 mm
                       •  Display : LCD touchscreen for all operation include parameter work in
                       •  Inflow Velocity : avg. 0.53 ± 0.025 m/s, Down flow Velocity : avg. 0.33 ± 0.025 m/s,
                       •  HEPA Filter : 99.99% efficient at 0.3 µm with filter life indicator
                       •  Material Work Zone : SUS 304 welded with a pharmaceutical grade finish
                       •  Main Body Material : Cold-Rolled steel with anti- bacteria epoxy powder coating
                       •  Work Surface Height : 750mm
                       •  Caster : Universal wheel with levelling feet
                       •  Power Supply :  220 V  60 Hz
                       •  Accessories : Fluorescence lamp (2 unit), UV Lamp (1 unit), Remote Control, Fo
               Dimension :

               BCS Unit:

                       •  1200 (W) x 900 (D) x 2400 (H) mm

               Scrubber Unit :

                       •  2400 (W) x 1800 (D) x 2340 (H) mm
