Page 942 - Quicksilver Accesories Guide 2019

PROPELLER HARDWARE AND ACCESSORIES

OUTBOARD JET IMPELLER SPORTJET IMPELLER

47-803985T 47-877326T
Mercury/Mariner 140/200 HP M2 jet drive 210 carb model 2000
M2 jet drive 240 EFI model 2000
SPORTJET IMPELLER
SPORTJET IMPELLER

47-828989T 1
90 jet (splined) 1993‑1995 47-883796T01
95 XR jet 1996‑1997 High skew impeller developed to provide improved holding or reduced cavitation
120 jet 1995 during acceleration and in turns. This impeller will produce an additional 75 RPM's
120 XR jet 1996‑1998 on top end in most cases. When used in the 250 application the REV limiter may
be activated more often than with the standard 4 blade impeller.
SPORTJET IMPELLER Fits the 175, 200, 210, 240 & 250 Jet Drive.

TOOLS
PLUG WRENCH/SCREW TOOL

47-854670T
120 XR2 jet 1999‑2000
SPORTJET IMPELLER

91-8M0026088
Plug Wrench/Screw Tool
PROPELLER NUT TOOL

47-835452T
175 XR2 jet 1997‑2000

91-805457T 1
For removal and installation of inner/front propeller nut. PROPELLER HARDWARE AND ACCESSORIES
Bravo Three

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 935
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
