Page 98 - Attwood Marine Products Collection 2020

INTEGRATED FUEL COMPONENTS

NOT FOR USE WITH EPA CERTIFIED SYSTEMS

Vented Deck Fills
Attwood’s plastic vented deck fills incorporate an industry first patent-pending waterproof screen that eliminates the possibility of water entering a boat’s fuel system,
while also allowing your boat’s engine to breath freely.These deck fills exceed the ISO 10088 standard for minimum required venting area and meet all ABYC and US Coat
Guard safety standards for marine fuel systems. Attwood’s unique design includes an integral tank vent with flame arrestor and anti-surge technology. CE certified to ISO
10088 enabling sales world wide.
Features:
• Integrated patent-pending waterproof screen • Round caps available in plastic, chrome or stainless
eliminates the possibility of water entering your steel to fit virtually any application and budget
boat’s fuel system • Stainless steel beaded chain to prevent loss of round
• Attwood’s unique design includes an integral tank Gasoline, Diesel and Water caps
vent with flame arrestor and anti-surge technology, • ISO symbols for Gasoline, Diesel, Water and Waste are
preventing fuel from escaping into the environment located on top of the cap
• Engineered body designed for extreme strength • Deck plate key is included with gasoline fill
• Choose from oval or round, straight or • Fits standard 1-1/2" fuel fill hose and 5/8" vent hose
angled configurations • Requires (4) #8 screws

Cap Bulk Prop Aftermarket Prop
Description Material Imprint Design Packaging 65 Packaging 65
OVAL VENTED DECK FILLS
Straight Black Plastic Gasoline Scalloped 99210GB1 —
Angled Black Plastic Gasoline Scalloped 99211GB1 —
ROUND VENTED DECK FILLS
Straight Black Plastic Gasoline Scalloped 99200GB1 —
Stainless Steel Gasoline Scalloped 99200GS1 —
Diesel Scalloped 99200DS1 —
Water Scalloped 99200WS1 —
Chrome Gasoline Scalloped 99200GZ1 —
Water Scalloped 99200WZ1 —
Angled Black Plastic Gasoline Scalloped 99201GB1 —
Stainless Steel Gasoline Scalloped 99201GS1 —
Diesel Scalloped 99201DS1 — 99211GB
Water Scalloped 99201WS1 —
Chrome Gasoline Scalloped 99201GZ1 —
Water Scalloped 99201WZ1 —
ROUND WASTE DECK FILLS 99200GS
Straight Stainless Steel Waste Scalloped 99202WS1 —
Chrome-plated Zinc Waste Scalloped 99202WZ1 —
Angled Stainless Steel Waste Scalloped 99202AWS1 —
Waste Y1 99202AWSY1-1 —

Y1 Flat cap

Scalloped cap

NON EPA CERTIFIED INTEGRATED FUEL COMPONENTS
