Model Name ROG-STRIX-LC-RX6900XT-T16G-GAMING ROG-STRIX-RX6900XT-LC-O16G-GAMING ROG-STRIX-RX6800XT-LC-O16G-GAMING

Card Photo Motherboards Motherboards

• TOP Edition • OC edition • OC edition
• Full-coverage cold plate • Full-coverage cold plate • Full-coverage cold plate
• On-board cooling • On-board cooling • On-board cooling
• 240mm radiator • 240mm radiator • 240mm radiator
Feature • 600mm tubing • 600mm tubing • 600mm tubing
• ASUS FanConnect II • ASUS FanConnect II • ASUS FanConnect II
• GPU Tweak II with Xsplit • GPU Tweak II with Xsplit • GPU Tweak II with Xsplit
Gamecaster Gamecaster Gamecaster
• wtfast • wtfast • wtfast Graphics Cards & PSUS Graphics Cards & PSUS
Product Series ROG Strix LC series ROG Strix LC series ROG Strix LC series
Graphics Engine AMD Radeon™ RX 6900 XT AMD Radeon™ RX 6900 XT AMD Radeon™ RX 6800 XT
Bus Standard PCI Express 4.0 PCI Express 4.0 PCI Express 4.0
Video Memory 16GB GDDR6 16GB GDDR6 16GB GDDR6
Gaming mode : 2525 MHz (Boost Clock) Gaming mode : 2365 MHz (Boost Clock) Gaming mode : 2360 MHz (Boost Clock)
2375 MHz (Game Clock) 2135 MHz (Game Clock) 2110 MHz (Game Clock)
Engine Clock

CUDA Code / 5120 5120 4608
Stream Processor Display Display
Memory Speed 16 Gbps 16 Gbps 16 Gbps
Memory Interface 256-bit 256-bit 256-bit
HDMI Output x 1 (HDMI 2.1) HDMI Output x 1 (HDMI 2.1) HDMI Output x 1 (HDMI 2.1)
Interface Display Port x 3 (Native) Display Port x 3 (Native) Display Port x 3 (Native)
(DisplayPort 1.4a) (USB Type-C) (DisplayPort 1.4a) (USB Type-C) (DisplayPort 1.4a) (USB Type-C)
Software ASUS GPU Tweak II & Driver ASUS GPU Tweak II & Driver ASUS GPU Tweak II & Driver
Card : 27.7 x 13.1 x 4.36 Centimeter Card : 27.7 x 13.1 x 4.36 Centimeter Card : 27.7 x 13.1 x 4.36 Centimeter Networks
Dimension Radiator : 27.6 x 12 x 5.17 Centimeter (including fan) Radiator : 27.6 x 12 x 5.17 Centimeter (including fan) Radiator : 27.6 x 12 x 5.17 Centimeter (including fan)
Networks
Model Name ROG-STRIX-RX6800-O16G-GAMING ROG-STRIX-RX6700XT-O12G-GAMING

Card Photo ODD & Storage ODD & Storage

• OC edition • OC edition
• Axial-tech Fan Design • Axial-tech Fan Design
• 2.9-slot design • 2.9-slot design
• Super Alloy Power II • MaxContact
• MaxContact heat spreader • Super Alloy Power II
Feature • reinforced frame • GPU Tweak
• FanConnect II • wtfast
• vented backplate Server & Workstation Server & Workstation

Product Series ROG Strix series ROG Strix series
Graphics Engine AMD Radeon™ RX 6800 AMD Radeon™ RX 6700 XT
Bus Standard PCI Express 4.0 PCI Express 4.0
Video Memory 16GB GDDR6 12GB GDDR6
Gaming mode : 2190 MHz (Boost Clock) OC mode : Up to 2622 MHz (Boost Clock) / Up to 2568 MHz (Game Clock)
Engine Clock
1980 MHz (Game Clock) Gaming mode : Up to 2622 MHz (Boost Clock) / Up to 2548 MHz (Game Clock)
CUDA Code / 3840 2560
Stream Processor Mini / Stick PC Mini / Stick PC
Memory Speed 16 Gbps 16 Gbps
Memory Interface 256-bit 192-bit
HDMI Output x 1 (HDMI 2.1) Yes x 1 (Native HDMI 2.1)
Interface Display Port x 3 (Native) Yes x 3 (Native DisplayPort 1.4a)
(DisplayPort 1.4a) (USB Type-C)
Software ASUS GPU Tweak II & Driver ASUS GPU Tweak II & Driver
13” x 5.07” x 2.26” Inch 322 x 141 x 56.5 mm
Dimension 32 x 12.87 x 5.73 Centimeter 12.68 x 5.55 x 2.22 inches Peripherals Peripherals
*Product specifications are subject to change without notice, although every effort is made to ensure that they are correct up to the point of launch.
Please contact your suppliers or local dealers for exact product launch schedules, specifications and availability.
