Balancing weight pliers Tool set for tire pressure monitoring
For fastening, loosening, and cutting off balancing weights. systems
Also for the expansion and compression of the retaining springs.
With plastic head on the hammer side. For the proper mounting of the monitoring sensors of Beru und
Especially for painted weights. Schrader and the pertinent special tire valves.
Chrome vanadium. Today, many manufacturers equip their vehicles with the corres-
Chrome-plated surface. ponding sensors, such as BMW (7 series, Z 8), MERCEDES-BENZ
(CL, E, S, SL Classes), OPEL (Vectra), and various vehicles of PEUGEOT,
CITROËN, RENAULT, AUDI, VW, and PORSCHE.
6-part set in plastic box with PUR insert.
Contents:
Valve rotator, hexagon socket wrench insert, size 11-12 mm,
hand adapter 6.3 ( ⁄4”), TORX screwdriver insert T 20, torque wrench
1
2-10 Nm
K Art. No. P. Qty. Art. No. 1952 000 711 P. Qty. 1
245 1952 000 709 1
Plastic impact head for 1952 000 709
1952 000 708 1

Wheel nut wrench
For the dismantling/mounting of wheel nuts/screws on utility vehicles.
Application of high power through particularly long lever arm up to
1430 mm (up to 1200 Nm when extended).
3-part - space-saving accommodation in a storage box or tool box
through the disassembly of the tool.
The double square extension also reaches into deep-lying screw
connections.
Handling of the socket wrench inserts of various sizes from the 9
program.
The fitting precision between the inside and outside tube guarantees a
secure seat in every length.
Pin securing mechanism against unintentional loosening
– Loosen the securing pin with the 3 mm dia. pin.
Inner square seat 9 connected to outside tube non-positively due to
special welding method.
Highly hardened and tempered special steel, burnished.

Pickup for adhesive balancing weights
For lifting weights and scraping residual adhesive off the wheel rim.
For light metal wheels.
With sharp-edged radial groove
with screwed in plastic part
(for scraping the residual adhesive off the edge of the disk).
Chrome vanadium.
High-gloss galvanized surface.
K o Art. No. P. Qty.
1035 - 1430 4 1952 000 715 1

K Art. No. P. Qty.
155 1952 000 002 1
