Plate shears nibbler Slide hammer puller (wheel hub puller)
For the cutting of plates up to 1.2 mm, Great pull-out force due to 5 kg slide weight in case of a long
plastic pipes up to 2 mm wall thickness acceleration distance makes a higher impact energy possible.
and transparent, wavy plastic material. To pull out 4 and 5 hole wheel hubs with a pitch circle dia.
Exchangeable tongue blade, relief ground. of 96 - 150 mm and hub dia. of a maximum of 67 mm.
Chip breaker made of chromium steel. For a maximum bolt dia. of 14 mm.
Grip covered with plastic. Special steel, galvanized.

K Art. No. P. Qty.
275 1952 000 207 1
Tongue blade for 1952 000 207
1952 000 208 1

Mounting wedge K Weight (kg) Art. No. P. Qty.
For body work, 1180 10.9 1952 000 211 1
e.g. for the damage-free loosening of trim, cover panels, labels,
and so on.
Plastic.

? Art. No. P. Qty. Door hinge pin remover
190 x 25 x 25 1952 000 209 1 For the dismantling of the clamping sleeves of door hinges.
Special steel.
Galvanized surface.
Axle puller Without pins (for the pertinent pins, see 1952 000 212 through
1952 000 215).
With 1.8 kg slide weight.
For pulling off the rear/full floating axle and
for pulling off 4 and 5 hole wheel hubs with a maximum dia. of 67 mm. Art. No. 1952 000 016 P. Qty. 1
Bolt dia. of 4-14 mm,
pitch circle dia. of 100-150 mm.
Special steel.
Galvanized surface.

K Weight (kg) Art. No. P. Qty.
Pulling pin
470 3.84 1952 000 210 1
For the door hinge pin remover 1952 000 016.
Special steel for very high stress.
Burnished surface.

MWF - 06/08 - 11523 - © • t K Art. No. P. Qty.
110
1952 000 212 1
3.85
110
5
1952 000 213 1
1952 000 214 1
125
5
1952 000 215 1
5.5
110
23
