Wireless Control System EV CLUSTER

CONTROLL & INFORMATION DISPLAY

• Capture battery pack information and identify problems • Set the driving mode of the vehicle
through wireless modules • Vehicle Information Display

• Check real-time battery pack via smartphone/personal PC • Check vehicle speed and travel distance, battery

• Verify the BMS firmware version and manage updates information, etc.
• Speed control, LED, charge control, cruise, constant line,
anti-theft function

MAIN SCREEN SYSTEM PAGE
⑨
⑦
⑧
⑥

① ② ③ ④ ⑤ ①
1.방향지시등 2.배터리전원 3.충전중
4.에러발생 5.전조등 6.배터리잔량
7.총 주행거리 8.주행모드 9. 고속 저속 모드
