Vehicle Control Technology

Encoder ■ Description

➢ Command output for Propulsion and Braking of EMU
➢ Manual or Propulsion/Braking command output according
ATO signal.
■ Specification
➢ Input Voltage : 70 ~ 125 VDC

➢ 24V/48V/60V, 400 ~ 500 Hz PWM Output Capacity: 15W

➢ Three Commend output for Braking
➢ DSP : 32Bit 28335

■ Feature

➢ PWM Output Control

➢ Redundancy function
➢ Applied LED Display.

➢ Detect potential-meter fail of Master Controller

■ Application

➢ Hyundai ROTEM ➔ Korail, Seoul Metro, Hong Kong, etc
