PROJECT Villas at Sarona
955 East Knox Road
Chandler, Arizona

COORDS. NE corner of Building 13
JOB NO. 17-2015-4066 DATE 12/16/15 See Site Plan
LOCATION CME-55
RIG TYPE
6 5/8" Hollow Stem Auger
BORING TYPE
DATUM
Depth in Feet Drill Rate Min/ft. Graphical Log Sample Sample Type Blow Count Dry Density lbs. per Cubic ft. Moisture Content Percent of Dry Weight Unified Soil or Rock Unit Classification SURFACE ELEV. VISUAL CLASSIFICATION
REMARKS
0
S 2-2-24 SC moist CLAYEY SAND, occasional coarse
A 9.4 grained, subangular gravel, predominantly
firm fine grainedsand,medium plasticity, brown

S 12-17- very firm note: landscape gravel at surface
17 to hard
below 2'

note: some calcium carbonate nodules
S 11-11-
5
14

S 14-25- note: light brown to tan from 7' to 15'
28

S 21-33-
10
34

15
S 10-17- note: light brown & trace manganese filaments
22 below 15'

S 11-14-
20
22
Stopped Auger at 19'6"
Stopped Sampler at 21'
Backfilled with drill cuttings

25
GROUNDWATER SAMPLE TYPE
DEPTH(ft) HOUR DATE A - Drill cuttings
none S - 2" O.D. 1.38" I.D. tube sample LOG OF TEST BORING NO. B-6
U - 3" O.D. 2.42" I.D. tube sample
NR - No Recovery
N/S - Not Sampled
