ADVANTAGES (continued)

Bitumen free. Safe for the environment.
High crack bridging capabilities of up to 2mm.
Produced from butyl rubber with both the adhesive bottom layer and the geotextile top layer bonded
during the manufacturing process.
For use in many different types of applications to replace bitumen based waterproof membranes.
Correct 50mm overlap joints are achieved during installation due to orange stripe marker on outside
edge of membrane.
No bentonite present so the product does not expand and break-up in water and/or wash from the
joint, removing the potential of voids between slab/wall and finishes. Butyl rubber gives long-term
durability and integrity to the product and in-turn to the joint and substrate.

AREAS OF APPLICATION

Railway station platform slabs and walls.
Viaducts and Bridges.
Power Stations and Utilities.
Electrical Riser Rooms.
Base slabs, walls and roofs for waterproofing (a topping slab must be applied)
Pipes, manholes and culverts.
Note : The product’s design and performance, its intended use, installation and final confirmation and approval for
use, must be provided by the project’s Design Engineer and Project Manager.

PHYSICAL PROPERTIES

DESCRIPTION TEST METHOD RESULT
Electrical ASTM D257 5.73 10^14 ohm-cm
Peel Adhesion ASTM D903 No Adhesion Failure
Adhesion Pull Off Strength ASTM D4541 No Adhesion Failure
Note : The above test results are based upon an independent laboratory test report and is available upon request.
Hydrocarbon blend content % by weight ASTM D-4 52min.
Inert mineral filler % by weight ASTM C-990 42min.
Volatile Matter % by weight ASTM C-990 1.20
Specific Gravity ASTM C-990 1.20-1.25
Ductility -13.9ºC ASTM D-113 -11.12min.
Penetration, Cone 25, 150CM. 5sec ASTM D-217 70-80mm
Softening point ºC ASTM D-36 168min.
Geotextile Fabric 100% Polypropylene
Application Temperature ºC -18 to +70
Service Temperature ºC -34 to +82
Shelf Life 5 Years from D.O.M
