Communication Security: Wireless • Chapter 4 203

number of open-source tools have appeared, which do precisely this.Two such
popular tools for cracking WEP are Airsnort and WepCrack.
Some vendors, such as Agere (which produces the ORiNOCO product line),
responded to the weakness in key scheduling by modifying the key scheduling in
their products to avoid the use of weak keys, making them resistant to attacks based
on weak key scheduling.This feature is known as WEPplus.

Stream Cipher Vulnerability

WEP uses an RC4 stream cipher, which differs from block ciphers such as DES or
AES, which perform mathematical functions on blocks of data, in that the data or
the message is treated as a stream of bits.To encrypt the data, the stream cipher per-
forms an Exclusive OR (XOR) of the plaintext data against the keystream to
create the ciphertext stream. (An XOR is a mathematical function used with
binary numbers. If the bits are the same the result of the XOR is “0”; if different,
the result of the XOR is “1.”)
If a keystream were always the same, it would be relatively easy to crack the
encryption if an attacker had both the plaintext and the ciphertext version of the
message (known as a plaintext attack).To create keystreams that are statistically
random, a key and a PRNG are used to create a keystream that is XOR’d against
the plaintext message to generate the ciphertext.
In the case of WEP, a number of other elements are involved to encrypt and
decrypt messages.To encrypt an 802.11 frame, the following process occurs:
1. A cyclic redundancy check (CRC), known as an ICV, is calculated for the
message and appended to the message to produce the plaintext message.
2. RC4 is used to create a pseudorandom keystream as a function of a 24-bit
IV and the shared secret WEP key.The IV and the shared secret WEP key
are used to create the RC4 key schedule.A new IV is used for every
frame to be transmitted.

3. The resulting keystream is XOR’d with the plaintext message to create a
ciphertext.
4. The IV is concatenated with the ciphertext in the appropriate field and
bit set to indicate a WEP-encrypted frame.
To decrypt the ciphertext, the receiving station does the following:

1. Checks the bit-denoting encryption.
