Communication Security: Web Based Services • Chapter 5 341

structure, even if one directory server is compromised, only a branch of the tree
(rather than the entire tree) is compromised.

Organizational Units

The hierarchy of an LDAP directory is possible because of the various objects that
make up its structure.These objects represent elements of the network, which are
organized using containers called organizational units (OUs). Each OU can be
nested in other OUs, similar to having subfolders nested in folders on your hard
disk. In the same way the placement of folders on your hard disk makes a directory
structure, the same occurs with OUs and objects in an LDAP directory.
The topmost level of the hierarchy generally uses the domain name system
(DNS) to identify the tree. For example, a company named Syngress might use
syngress.com at the topmost level. Below this, organizational units are used to iden-
tify different branches of the organization or network. For example, you might have
the tree branch off into geographical locations, like PARIS, LONDON, and
TORONTO, or use them to mimic the organizational chart of the company, and
create OUs with names like ADMINISTRATION, RESEARCH,TECH-
NOLOGY, etc. Many companies will even use a combination of these methods,
and use the OUs to branch out by geographical location, and then create OUs for
divisions of the company within the OUs representing locations.
To identify the OUs, each has a name that must be unique in its place in the
hierarchy. For example, you can’t have two OUs named PRINTERS in a con-
tainer named SALES.As with many elements of the directory it is analogous to
the directory structure of a hard disk where you can’t have two subfolders with
the same name in the same folder.You can however have OUs with the same
name in different areas of the hierarchy, such as having an OU named
PRINTERS in the SALES container and another OU named PRINTERS in an
OU named SERVICE.
The structure of the LDAP directory is not without its own security risks, as it
can be a great source of information for intruders.Viewing the placement of OUs
can provide a great deal of information about the network structure, showing
which resources are located in which areas of the organization. If an administrator
followed a particular scheme of designing the hierarchy too closely, a hacker could
determine its structure by using information about the organization. For example,
companies often provide their organizational charts on the Internet, allowing
people to see how the company is structured. If an administrator closely followed
this chart in designing a hierarchy, a hacker could speculate how the LDAP direc-
