Top-Ported Pressure Filter MHS60

NF30
Type Fluid Appropriate Schroeder Media Fluid
High Water Content All Z-Media (synthetic) Compatibility NFS30
®
®
Invert Emulsions 10 and 25 µ Z-Media (synthetic)
Water Glycols 3, 5, 10 and 25 µ Z-Media (synthetic) YF30
®
Phosphate Esters All Z-Media (synthetic) with H (EPR) seal designation
®
CFX30
PLD
Element Element selections are predicated on the use of 150 SUS (32 cSt) Element
Pressure Series Part No. petroleum based fluid and a 50 psi (3.4 bar) bypass valve. Selection DF40
13HZ3 13HZ3 Based on
Flow Rate CF40
Z- 13HZ5 13HZ5
Media ® 13HZ10 13HZ10
To 13HZ25 13HZ25 PF40
6000 psi
(415 bar) Z- 13HZX3 13HZX3 RFS50
Media ® 13HZX5 13HZX5
(High 13HZX10 13HZX10 RF60
Collapse)
13HZX25 13HZX25
gpm 0 20 40 60 80 100 CF60
Flow
(L/min) 0 75 150 225 300 380
CTF60
Shown above are the elements most commonly used in this housing.
VF60

∆P housing ∆P element Pressure LW60
MHS60 ∆P housing for fluids with sp gr = 0.86: ∆P element = flow x element ∆P factor x viscosity factor Drop KF30
Information
Flow (L/min) El. ∆P factors @ 141 SUS (30 cSt): Based on
(190) (380) 13HZ3 0.134 13HZX3 0.176 Flow Rate TF50
50 3.3 13HZ5 0.098 13HZX5 0.104 and Viscosity
40 2.7 13HZ10 0.060 13HZX10 0.054 KF50
13HZ25 0.043 13HZX25 0.048
∆P psi 30 2.0 ∆P (bar) KC50
20
1.3
bars & L/min, divide
10 0.7 If working in units of MKF50
above factor by 54.9.
0 0.0 Viscosity factor: Divide KC65
0 50 100 150 viscosity by 141 SUS (30
Flow gpm cSt).
NOF30-05
sp gr = specific gravity
NOF50-760
Sizing of elements should be based on element flow information provided in the Element Selection chart above.
FOF60-03
∆P filter = ∆P housing + ∆P element
Exercise: NMF30
Determine ∆P at 85 gpm (320 L/min) for
HS60... using 141 SUS (30 cSt) fluid. RMF60
Solution:
∆P housing = 13.5 psi [0.93 bar] Cartridge
∆P element = 85 x .134 x (141÷141) = 11.39 psi Elements
or
= [320 x (.134÷54.9) x (32÷32) = .79 bar] HS60
∆P total = 13.5 + 11.39 = 24.89 psi
or MHS60
= [.93 + .79 = 1.71 bar]
KFH50

SCHROEDER INDUSTRIES 145
