Page 275 - Schroeder - Hydraulic And Lube Filtration

Tank-Mounted Filter ART

Type Fluid Appropriate Schroeder Media Fluid IRF
Petroleum Based Fluids All Z-Media (synthetic) Compatibility TF1
®
High Water Content All Z-Media (synthetic)
®
KF3

Element Element KL3
Element selections are predicated on the use of 150 SUS (32 cSt) petroleum
Pressure Series Part No. based fluid and a 43 psi (1.7 bar) bypass valve (with check valve option). Selection
Based on LF1–2"
85Z1 85Z1 Flow Rate
Return 85Z3 85Z3 MLF1
Line Z-
-Tank- Media 85Z5 85Z5
Mounted 85Z10 85Z10 RLD
85Z25 85Z25
gpm 0 25 50 75 100 125 150 175 200 225 KT
Flow
(L/min) 0 95 190 285 380 475 570 665 760 850
MTA
Shown above are the elements most commonly used in this housing.
* Note: Additional per element flow is available up to 300 gpm when using ART filter without check valve
option.
See housing pressure drop graph below. MTB
Note: Contact factory regarding use of E Media in High Water Content, Invert Emulsion and Water Glycol
Applications. For more information, refer to Fluid Compatibility: Fire Resistant Fluids, pages 19 and 20. ZT

KFT

Pressure RT
∆P housing ∆P element
Drop
ART ∆P housing for fluids with sp gr = 0.86: ∆P element = flow x element ∆P factor x viscosity factor Information RTI
El. ∆P factors @ 150 SUS (32 cSt):
Flow (L/min) Based on
4 (212.5) (425) (637.5) Z Flow Rate LRT
and Viscosity
3.5 85Z1 .22
3 (0.21) 85Z3 .12 ART
.1
∆P psi 2.5 2 (0.14) ∆P (bar) 85Z5 .08 BFT
85Z10
1.5
1 (0.07) 85Z25 .03
0.5 If working in units of bars & L/min, divide above QT
factor by 54.9.
0
0 25 50 75 100 125 150 175 200 225 Viscosity factor: Divide viscosity by 150 SUS (32 cSt).
Flow gpm KTK
sp gr = specific gravity
Sizing of elements should be based on element flow information provided in the Element Selection LTK
chart above.
MRT
Notes ∆P filter = ∆P housing + ∆P element
Exercise:
Determine ∆P at 160 gpm (600 L/min) Accessories
for ART85Z5S43Y2 using 175 SUS (44 cSt) fluid. for Tank-
Mounted
Solution:
∆P housing = 1.9 psi [.17 bar] Filters
∆P element = 160 x 0.1 x (175÷150) = 18.67 psi
or PAF1
= [600 x (0.1÷54.9) x (38÷32) = 1.30 bar]
∆P total = 1.9 + 18.67 = 20.57 psi
or MAF1
= [.17 + 1.30 = 1.47 bar]
MF2

SCHROEDER INDUSTRIES 273
