Accessories for Tank-Mounted Filters

The mounting ring is welded directly to the hydraulic reservoir. Mounting IRF
The filter is then mounted to the mounting ring with bolts Ring
converting the filter to a “weld in” design. The mounting TF1
ring eliminates the need to drill and tap the hydraulic reservoir. for ST, ZT,
RT, RTI and
Model Part LRT Models KF3
Number Number A B C
ST, RT, A-LFT-813 7.00 5.00 1.00 KL3
RTI, LRT (178) (127) (25)
ST, RT, RTI, 7.00 5.00 1.50 LF1–2"
LRT High A-LFT-1448 (178) (127) (38)
Version
ZT 6.25 3.62 .88 MLF1
A-LFT-1295
(159) (92) (22)
RLD
The diffuser option (designated as D for outlet porting option Diffuser GRTB
in model number) is threaded to the bushing on the filter bowl for KFT, RT and
below the outlet opening to help decrease turbulent flow in the
hydraulic reservoir. LRT Models MTA
No other outlet port options are available if the diffuser is used.
MTB
Model Part
Number Number NPTF
RT, KFT A-LFT-1506 1 ⁄2" ZT
1
LRT A-LFT-1507 2"
KFT

The check valve option (designated as C for outlet porting Check Valve RT
option in model number) makes it possible to service the for ST, KFT,
filter without draining the oil from the reservoir when the RTI
filter is mounted below the oil level. It also prevents reservoir RT, LRT and
siphoning when system components are serviced. BFT Models
LRT
The check valve can also be used on other reservoir return flow
lines, where components upstream of the check valve can be
serviced without the loss of reservoir oil. The spring setting is ART
.75-1.00 psi cracking. Order by part number shown in chart.
No other outlet port options are available if the check valve BFT
is used.
Model Part QT
Number Number NPTF A
1
ST, KFT, RT A-LFT-158Q-1 1 ⁄2" 2.34 (59)
LRT A-LFT-880 2" 2.34 (59) KTK
BFT A-BFT-103 3" 4.50 (114)
LTK

The diffuser/check valve option (designated as CD for outlet Check MRT
porting option in model number) is threaded on to the outlet Valve
port and combines the advantages of both separate options Accessories
in one assembly. Diffuser
Combination for Tank-
1
Available as a separate item with 1 ⁄2" NPT female threads, Mounted
order part number A-LFT-1208. for KFT and
RT Models Filters
No other outlet port options are available if the check valve/
diffuser is used.
PAF1
MAF1

MF2

SCHROEDER INDUSTRIES 295
