Attachment and Accessories

Attachment for Column Mounted Jib Cranes

Crane column Anchor set Anchor bolts Mobile base plate
• High quality welded steel con- • High quality injection mortar • Use when concrete quality • No need to attach to the floor
struction, RAL 7035 light gray anchor is low • Can be easily transported by
coating (special coating upon • Required cement thickness: • Dimensions of the foundations means of a forklift or pallet
request) min. 200 mm; required concrete from 1,200 x 1,200 mm to truck
• Fitted with anchors quality: min. B25 or C25/235 2,300 x 2,300 mm • Dimensions from
• Space-saving dimensions of • No additional foundation • For loads weighing up to 990 kg 1,200 x 1,200 mm to
the base plate (400 x 400 mm necessary 1,470 x 1,470 mm
to 960 x 960 mm) • For loads weighing up to 990 kg • For loads weighing up to
200 kg (depending on the jib
length)

Attachment for Wall Mounted Jib Cranes

Wall bracket Clasp bracket Anchor set Counter plate
• Steel console, RAL 7035 light • For mounting the wall bracket • High quality injection mortar • Counter plate with clearance
gray coating (special coating to an existing production hall anchor for attachment to walls holes for attachment to walls
upon request) pillar or column (wall thickness min. 200 mm)
• For loads weighing up to 110 kg
(depending on the jib length)

Accessories

Slewing angle limiter Blower console Integrated Motor protection switch
• Limit stop for individual adjustment of the • For attaching vacuum generators directly to • To protect electrical devices against
swiveling range the crane column overvoltage
• The limit for each swivel side is 45° to 135° • Easy mounting by means of a clasp • Can be locked, optional and therefore
suitable as main switch
