B. Jib Cranes
What is the size of the coverage area [mm]? Radius
Is a slewing angle limiter required?
e.g. in the event of interference from pillars in the
production hall, pipes or cable bridges No Yes
What is the ceiling height [mm]?
What lifting height is required [mm]?
Lower edge of jib minus height of the hoist
What type of crane attachment is needed? Column mounted jib crane
Anchored With mobile base plate
Wall mounted jib crane
Existing production
Concrete wall
hall pillar
Space for Your Drawing
Do You Need Help Filling out the Questionnaire?
