4 I/O-System — 750 and 753 Series — One System for Every Application
118 General Product Information

Maximum Fieldbus Independence Extremely Compact
One System for Every Application
The system’s modularity is also reflected in its Our patented mechanical design leads to
The WAGO-I/O-SYSTEM 750/753 is support for numerous fieldbus systems and extremely compact I/O nodes. In fact, select I/O
characterized by its universal application ETHERNET standards. Depending on the modules can accommodate up to 16 channels in
scope and extensive product portfolio. application, it is possible to choose between a 12 mm (1/2”) wide housing.
• Finely granular I/O modules enable
With more than 500 different modules, fieldbus couplers and communication modules customization of nodes
the versatility and flexibility is so great that for different protocols. • Space-saving design allows high
virtually every requirement in a wide range integration density and direct connection
of industries is covered. Easy to Use
The modular, rail-mounted module design permits Maximum Reliability and Ruggedness
Industrial Automation easy, tool-free installation and straightforward The WAGO-I/O-SYSTEM is also designed for
The wide selection of I/O modules for modifications, such as system expansions. The applications operating under the most deman-
various potential and signal forms, as well ding environmental conditions in accordance with
as specialty functions, makes it possible straightforward design prevents installation errors. the highest standards, e.g., those required in ship-
®
to economically wire sensors/actuators — In addition, proven CAGE CLAMP technology building. The system is distinguished from other
even in safety-related applications. offers fast, vibration-proof and maintenance-free
connections that are independent of operator products that are solely intended for industrial use
because of:
Building Automation skill. Depending on the I/O module’s granularity, • Greatly increased vibration rating
The broad portfolio allows for flexible, the field peripherals can be wired directly using • Significantly greater immunity to interference
cellar-to-ceiling solutions with conventional 1-, 2-, 3- or 4-wire technology. (ESD)
I/O modules, standardized industry-
specific fieldbus protocols and subsystems Worldwide Approvals • Lower emission of interference
for typical applications in lighting, shading, International approvals for building and industrial • Larger voltage fluctuation range
heating, ventilating and air conditioning automation, as well as the process and shipbuil- • Improved ruggedness for continuous operation
(HVAC) and more. in a temperature range near the limit
ding industries guarantee worldwide use even
®
Marine and Onshore/Offshore under harsh operating conditions, e.g., ATEX, In addition, CAGE CLAMP spring pressure
Automation BR-Ex, IECEx, UL 508 and UL ANSI/ISA. connections ensure superior reliability.
Integrated QA measures in the production pro-
International approvals coupled with cess and 100 % function testing ensure consistent
industry-specific features permit use in ship- quality.
building and other harsh sectors. Address-
ing industry- and operating environment- Clear Identification
specific requirements has enabled use on Pullout group markers identify module functio-
marine diesels and in the EMC-sensitive nality (integrated or as an option). Connector
area of a vessel’s bridge. Because WAGO assignment and technical data are located on the
meets the marine industry’s significantly side of the module. The WAGO WSB marker sys-
greater requirements for immunity to r tem also allows for module- and channel-related
interference or emission of interference and identification.
mechanical performance, WAGO I/O is
well-suited to other industries. & /

Process Automation
Use even under the harshest environmental g
conditions is possible with special approv-
als. Potential hazardous location applica-
tions include oil and gas production, the
chemical industry and power generation.
The WAGO-I/O-SYSTEM can be installed
in Zone 2/22 with its intrinsically safe I/O
modules making it possible to connect sen-
sors/actuators in Zones 1/21 and 0/20.
● Fieldbus-independent — compatible with all standard
fieldbus protocols & ETHERNET standards
● Flexible platform adapts to diverse applications and environments
● Tested and approved worldwide
● Wide range of accessories for marking and connection technology
● CAGE CLAMP connection technology for vibration-proof,
®
fast and maintenance-free connection
