Page 159 - Gefran - Inverter system and power supply unit (ADV200 Drive family)

Gefran Spa - Drive & Motion Control Unit • www.gefran.com 159

Table 4: output choke (Motor cable lenght distance > 100 m)

Size Output inverter Q.ty Model Code Dimensions and Weights ADV200-4 ADV200-DC ADV200-6 ADV100 AFE200 ADV200 - 4

ADV200-4
ADV-72000-KXX-4-MS 04 1 LU3-200 S7AF0 W x H x d: 300 x 270 x 230 mm l l ADV200-DC
400 kW HD
ADV-72000-XXX-4-SL 1 LU3-200 S7AF0 33 kg l l
ADV-72000-KXX-4-MS 04 1 LU3-315 S7FH9 W x H x d: 370 x 400 x 210 mm l l
400 kW LD
ADV-72000-XXX-4-SL 1 LU3-315 S7FH9 65 kg l l
ADV-72500-KXX-4-MS 05 1 LU3-400 S7FO8 l l
500 kW HD / LD
ADV-72500-XXX-4-SL 1 LU3-400 S7FO8 l l ADV200 - 6
ADV-73150-KXX-4-MS 06 1 LU3-400 S7FO8 l l
630 kW HD / LD
ADV-73150-XXX-4-SL 1 LU3-400 S7FO8 l l
W x H x d: 390 x 430 x 270 mm
ADV-73150-KXX-4-MS 07 1 LU3-400 S7FO8 l l
710 kW HD / LD 73 kg
ADV-73150-XXX-4-SL 1 LU3-400 S7FO8 l l
ADV-73150-KXX-4-MS 09 1 LU3-400 S7FO8 l l ADV100
900 kW ADV-73150-XXX-4-SL HD / LD 1 LU3-400 S7FO8 l l
ADV-73150-XXX-4-SL 1 LU3-400 S7FO8 l l
ADV-73150-KXX-4-MS 10 1 LU3-400 S7FO8 l l
W x H x d: 390 x 430 x 270 mm
1 MW ADV-73150-XXX-4-SL HD / LD 1 LU3-400 S7FO8 l l
73 kg
ADV-73150-XXX-4-SL 1 LU3-400 S7FO8 l l ADV80
ADV200-6
ADV-72000-KXX-6-MS 04 1 LU3-6-200 S7FO17
400 kW HD l
ADV-72000-XXX-6-SL 1 LU3-6-200 S7FO17 W x H x d: = 300 x 360 x 210 mm
ADV-72000-KXX-6-MS 04 1 LU3-6-250 S7FO18 46 kg
400 kW LD l
ADV-72000-XXX-6-SL 1 LU3-6-250 S7FO18
ADV-72500-KXX-6-MS 05 1 LU3-6-ADV-400 S7FO19 AFE200
500 kW HD/LD l
ADV-72500-XXX-6-SL 1 LU3-6-ADV-400 S7FO19
ADV-73150-KXX-6-MS 06 1 LU3-6-ADV-400 S7FO19
630 kW HD l
ADV-73150-XXX-6-SL 1 LU3-6-ADV-400 S7FO19
ADV-73150-KXX-6-MS 06 1 LU3-6-ADV-400 S7FO19
630 kW LD l
ADV-73150-XXX-6-SL 1 LU3-6-ADV-400 S7FO19 FFE200
ADV-73150-KXX-6-MS 07 1 LU3-6-ADV-400 S7FO19
710 kW HD/LD l
ADV-73150-XXX-6-SL 1 LU3-6-ADV-400 S7FO19
ADV-73150-KXX-6-MS 09 1 LU3-6-ADV-400 S7FO19
900 kW ADV-73150-XXX-6-SL HD/LD 1 LU3-6-ADV-400 S7FO19 l
ADV-73150-XXX-6-SL 1 LU3-6-ADV-400 S7FO19 SMB200
W x H x d: = 360 x 350 x 250 mm
ADV-73150-KXX-6-MS 10 1 LU3-6-ADV-400 S7FO19
65 kg
1 MW ADV-73150-XXX-6-SL HD/LD 1 LU3-6-ADV-400 S7FO19 l
ADV-73150-XXX-6-SL 1 LU3-6-ADV-400 S7FO19
ADV-73550-KXX-6-MS 10 1 LU3-6-ADV-400 S7FO19 l
ADV-73550-XXX-6-SL 1 LU3-6-ADV-400 S7FO19 l
1.35 MW HD/LD
ADV-73550-XXX-6-SL 1 LU3-6-ADV-400 S7FO19 l PROGRAM.
ADV-73550-XXX-6-SL2 1 LU3-6-ADV-400 S7FO19 l
ADV-73550-KXX-6-MS 17 1 LU3-6-ADV-400 S7FO19 l
ADV-73550-XXX-6-SL 1 LU3-6-ADV-400 S7FO19 l
1.65 MW ADV-73550-XXX-6-SL HD/LD 1 LU3-6-ADV-400 S7FO19 l
ADV-73550-XXX-6-SL2 1 LU3-6-ADV-400 S7FO19 l APPENDIX
ADV-73550-XXX-6-SL2 1 LU3-6-ADV-400 S7FO19 l
