Vacuum Layer Gripping Systems SPZ

Schmalz vacuum gripping systems can be modifi ed with different Further information
expansion options for virtually any process-specifi c requirements. With Technical data and
every design step, more complex functionalities through more gripping further information on the
principles, for example, are possible. Pneumatic, mechanical and sensory SPZ can be found here.
options from the modular system enable handling applications in almost
all industries.

Confi guration examples

SPZ SPZ
• Suction area • Suction area (foam or suction cups)
(foam or suction cups) • Confi gurable size
• Confi gurable size • Mechanical gripper support
• Intermediate layer handling
• Pallet clamping

SPZ-M SPZ-M
• Suction area • Suction area (foam or suction cups)
(foam or suction cups) • Confi gurable size
• Confi gurable size • Mechanical gripper support
• Mechanical gripper support • Intermediate layer handling
• Intermediate layer handling • Pallet clamping
• Pallet clamping • Automatic parts monitoring
• Automatic parts monitoring • Variable height adjustment

SPZ-M-C SPZ-M-C
• Suction area (foam or suction cups) • Suction area (foam or suction cups)
• Confi gurable size • Confi gurable size
• Mechanical gripper support • Mechanical gripper support
• Intermediate layer handling • Intermediate layer handling
• Pallet clamping • Pallet clamping
• Automatic parts monitoring • Automatic parts monitoring
• Global vacuum chamber • Global vacuum chamber
• Variable height adjustment
• Suitable for freezer environments
