Switchgear Cabinet Drawer
                                                                                                                   11

                                                                                                                   523

          Switchgear cabinet drawer
























                                      Pack.
                      Item No.
                                      Unit
          Switchgear cabinet drawer,
          DIN 35-rail mount drawer
                      709-591         1







                                                                                The switchgear cabinet drawer is the ideal place to store
                                                                                small parts that are not constantly used (e.g., instructions,
                                                                                test plug adapters, jumpers, spare fuses).




























                                                                                                                   11

                    45 mm         76 mm






                              54 mm

          Dimensions in mm
          Height from upper-edge of DIN 35 rail
