RPW-750M Series

2-Jaw Heavy-Duty Parallel Grippers | Dimensions and Technical Specifications

2X Ø 8 H7 X 9 DP
L C 38.1 [1.500]

2X 99.8
L C
[3.928] (JAW)

100.0 [3.937] 139.70 [5.5000] 6X M8 X 12 DP
(BODY)
180.9 [7.125]

2X Ø Ø 8 H7 X 12 DP (THIS FACE ONLY)
4X M10 X 16 DP (THIS FACE ONLY)
L C

L C 2X 75.0
[2.942] (JAW)
75.0 [2.952] 63.5 2X 49.8 [1.960]
(BODY) [2.500]
101.60 [4.0000]
139.7 [5.500]

30 2X M5 X 6 DP DP (SENSOR MNTG HOLES)
10 [.38] 25 [1.19] 2X G1/8" AIR PORTS (OPEN)
5 41
[.19] [1.00] [1.62] L C 32 [1.25] L C
5 [.19]
L C 4X Ø 8 H7 X 12 DP L C 60.33 85.7
[2.3750] [3.375]

8X M10 X 25 DP
76 [3.00] 42.2
2X M4 X 6 DP
(SENSOR [1.660]
TARGET CLOSE
MNTG HOLES)
410 [16.14] (OPEN) Sensor Accessories 750
296 [11.65] (CLOSED)
JAWS SHOWN OPEN Inductive Sensor Mtg Kit (2 Sensors) OSMK-014
Seal Repair Kits 750
Standard Seal Repair Kit SLKT-060
Viton Seal Repair Kit SLKT-060V
®
Loading Information
Z Z
MZ
N lbs. GRIP FORCE PER FINGER
1113 250 DO NOT EXCEED L C T Y F/2 F/2
X
WARNING!
FINGER FORCE - F/2 668 150 80 PSI [5.5 bar] MAXIMUM EFFECTIVE MX MY
890
200
100 PSI [7 bar]
FINGER LENGTHS
445
100
60 PSI [4.1 bar]
40 PSI [2.7 bar]
RPW-750M
Static
Dynamic
223
50
Maximum Tensile T [2500 lb] 11121 N [250 lb] 1112 N
0 0
0 4 8 12 16 20 in. Maximum Compressive C [2500 lb] 11121 N [250 lb] 1112 N
0 102 203 305 406 508mm Maximum Moment Mx [2000 in.-lb] 226 Nm [200 in.-lb] 22 Nm
EFFECTIVE FINGER LENGTH - L
Maximum Moment My [3000 in.-lb] 339 Nm [250 in.-lb] 28 Nm
Maximum Moment Mx [2000 in.-lb] 226 Nm [200 in.-lb] 22 Nm
† Capacities are per set of jaws and are not simultaneous
