Fulfl o CH Filter Vessels
®

Carbon Steel, 304 and 316 SS Cartridge Filter Vessel Series

Available Finishes Product Confi gurations
• Enamel exterior paint on carbon Pipe size or connection:
steel models 2” NPT inlet & outlet
• Glass bead blast fi nish on 1/2” NPT vent
stainless models 3/4” NPT drain

Number of Cartridges Fulfl o® CH Vessel Series
Five 10 inch, 20 inch or 30 inch Rated Capacity
x 2.70” OD (Max) end caps 25 gpm, 50 gpm, 75 gpm

Cartridge Confi gurations
Flat
222 O-ring Temperature Guide
O-ring PP spring closed end Material Max. Temp.
SOE
Flex fi n
Nitrile (Buna-N) 250ºF (121ºC)
Gasket PP spring closed end
SOE EPDM 300ºF (149ºC)
Standard Silicon 300ºF (149ºC)
DOE
®
Extended Core FKM (Viton ) 400ºF (204ºC)
Dimensions Max. Allowable Max. Allowable
Shipping Material of
Model OAH Pressure (MAP) Temp. (MAT)
A Wt. (lbs) Construction
Max. (psi @ MAT ºF) (ºF @ MAP psi)
CHC5S2T 19.00 38.00 57 Carbon Steel 175 psi (12.1 bar) 400ºF (204ºC)* **
CHC5D2T 29.00 48.00 67
304 Stainless 175 psi (12.1 bar) 400ºF (204ºC)**
CHC5T2T 39.00 58.00 77
CHG5S2T 19.00 38.00 57 316 Stainless 175 psi (12.1 bar) 400ºF (204ºC)**
CHG5D2T 29.00 48.00 67
*Limited to 250ºF by the paint
CHG5T2T 39.00 58.00 77
CHS5S2T 19.00 38.00 57 **Limited to 250ºF by the std. Buna-N o-ring
CHS5D2T 29.00 48.00 67
CHS5T2T 39.00 58.00 77
Ordering Information
TECHNICAL SUPPORT and PRODUCT
ORDERING
CH 5 Parker Process Advanced Filtration provides
unsurpassed product consistency and
cost-effi ciency for our customers. Our
experienced professionals can help you
select the right solution for your application.
Material Element Length Inlet/Outlet Flange Size Support Options
For more information or to place an order,
C Carbon Steel S 10" 2T 2” NPT Blank Zinc plated carbon steel legs contact your local distributor. Information
on product specifi cations, applications and
G 304 Stainless Steel D 20" W Wall Mounted/No legs
chemical compatibility can be found on
S 316 Stainless Steel T 30" SL Stainless steel legs our web site at www.parker.com or through
your nearest Parker Process Advanced
SB Stainless steel cover bolts Filtration offi ce. Parker Process Advanced
Filtration designs and manufactures an
SS Stainless steel bolts & legs
Example Part# Confi guration for Orders (no dashes): extensive line of innovative solutions for
specifi c applications in Biopharmaceutical,
CHC5S2T Microelectronics, Food & Beverage,
CHG5D2TSL
Industrial and Chemical industries.
© 2009 Parker Hannifi n Corporation SPEC C4022 7/09
Specifi cations are subject to change without notifi cation.
Viton is a registered trademark of E.I. DuPont de Nemours & Co., Inc.
