Mining Specific Elements

Schroeder Part Numbers: SBF-WS3L-150PSB (150μm) & SBF-WE3L-Z10B
(10μm)
A 20.18 (512.57)

3.94 (100.10) 7.24 (183.90)

A
S E C O I T N A - A

Specifications SBF-WS3L-150PSB: Schroeder BestFit P/N
TM
Micron Rating: 150μm SBF-PF3L-Z12B
SBF-WE3L-Z10B: 10μm SBF-WE3L-Z60B
Collapse Rating: 150 psid (min) SBF-WS3L-Z10B
End Cap: Anodized Aluminum Seebach Element P/N
Outer Support Tube: Stainless Steel SA12MB-PF3L-95/5
SA75FBWE3L-Water
Filter Media: SBF-WS3L-150PSB:
150μm synthetic SA12MB-WS3LP-95/5
SBF-WE3L-Z10B: 150μm Seebach Filter
synthetic Triple "L" Filter
O-Ring: Buna N Triple "L" Filter
Triple "L" Filter
*Contact factory for additional filter ratings

Schroeder Part Number: SBF - SALL - 40Z150B & SBF- SALL - 40Z10B

40.08 (1018.03)
A

6.70 (170.20)
4.63 (117.60)
A

S E C O I T N A - A

Specifications
SBF-SALL-40Z150B:
TM
Micron Rating: 150μm Schroeder BestFit P/N
SBF-SALL-40Z10B: 10μm SBF-SALL-40Z150B
Collapse Rating: Not Rated SBF-SALL-40Z10B
End Caps: Anodized Aluminum Seebach Element P/N
Support Tube: None SALL40FB-150-Water
Filter Media: SBF-SALL-40Z150B: SALL40G010-95/5
150μm synthetic Seebach Filter
SBF-SALL-40Z10B: 10μm
synthetic 2UC3230-000
O-Ring: Buna N 2UC3230-000
*Contact factory for additional filter ratings

100 SCHROEDER INDUSTRIES | PROCESS FILTRATION
