PDE2600PNUK
Parker Pneumatic Legris - PE Tubing

1030Y..F Advanced Polyethylene (APE) Tubing 1096Y..F Advanced Polyethylene (APE) Tubing

Drum 300 m Drum 250 m

o.d. tubing i.d. tubing Minimum bend Order code o.d. tubing i.d. tubing Minimum bend Order code
mm mm radius for tube at inch inch radius for tube at
ambient temp. ambient temp.
in mm in mm
Polyethylene Polyethylene
4 2.5 16 1030Y04F00 1/2 0.375 1.96 1096Y62F00
4 2.5 16 1030Y04F01 1/2 0.375 1.96 1096Y62F01
4 2.5 16 1030Y04F02 1/2 0.375 1.96 1096Y62F02
4 2.5 16 1030Y04F03 1/2 0.375 1.96 1096Y62F03
4 2.5 16 1030Y04F04 1/2 0.375 1.96 1096Y62F04
4 2.5 16 1030Y04F05 1/2 0.375 1.96 1096Y62F05
4 2.5 16 1030Y04F10 clear 1/2 0.375 1.96 1096Y62F10 clear
6 4 32 1030Y06F00
6 4 32 1030Y06F01 1098Y..F Advanced Polyethylene (APE) Tubing
6 4 32 1030Y06F02
6 4 32 1030Y06F03 Drum 500 m
6 4 32 1030Y06F04
6 4 32 1030Y06F05
6 4 32 1030Y06F10 clear

1075Y..F Advanced Polyethylene (APE) Tubing o.d. tubing i.d. tubing Minimum bend Order code
inch inch radius for tube at
Drum 75 m ambient temp.
in mm

Polyethylene
1/4 0.170 0.78 1098Y56F00
1/4 0.170 0.78 1098Y56F01
1/4 0.170 0.78 1098Y56F02
o.d. tubing i.d. tubing Minimum bend Order code 1/4 0.170 0.78 1098Y56F03
mm mm radius for tube at 1/4 0.170 0.78 1098Y56F04
ambient temp. 1/4 0.170 0.78 1098Y56F05
in mm
Polyethylene 1/4 0.170 0.78 1098Y56F10 clear
3/8 0.250 1.18 1098Y60F00
12 9 55 1075Y12F00 3/8 0.250 1.18 1098Y60F01
12 9 55 1075Y12F01 3/8 0.250 1.18 1098Y60F02
12 9 55 1075Y12F02 3/8 0.250 1.18 1098Y60F03
12 9 55 1075Y12F03 3/8 0.250 1.18 1098Y60F04
12 9 55 1075Y12F04 3/8 0.250 1.18 1098Y60F05
12 9 55 1075Y12F05 3/8 0.250 1.18 1098Y60F10
12 9 55 1075Y12F10 clear clear
14 11 75 1075Y14F00 clear
16 13 95 1075Y16F00 clear 1099Y..F Advanced Polyethylene (APE) Tubing
Drum 1000 m

o.d. tubing i.d. tubing Minimum bend Order code
inch inch radius for tube at
ambient temp.
in mm
Polyethylene
1/4 0.170 0.78 1099Y56F00
1/4 0.170 0.78 1099Y56F01
1/4 0.170 0.78 1099Y56F02
1/4 0.170 0.78 1099Y56F03
1/4 0.170 0.78 1099Y56F04
1/4 0.170 0.78 1099Y56F05
1/4 0.170 0.78 1099Y56F10 clear

Parker Hannifin Corporation
Fluid Connectors Group
760
