Page 53 - Parker - Industrial Hydraulics

Accumulators/ Compact Cylinders Filtration Fluid Motors Power Pumps Pumps/ Rotary Valves
Coolers Hydraulics Connectors Units Motors Actuators

Valves – Hydraulic

Pressure Control Valves

In-Line Mounted Manifold-Mounted
• Right angle or in-line-style valves • Pilot operated, normally closed,
• Pressure ranges between 0.25 and quick response and spool-type
62**, 63**, 64** 250 bar (4 and 3600 psi) valves available
• Soft-seat poppets in brass or • Pressure range of 25 to 350 bar
stainless steel for near zero leaks (363 to 5075 psi)
• Non-standard and special port • Subplate or slip-in mounting offered
styles available on request • 2 or 3 adjustment modes
665

VM VB
VBY R, RS

VS
UR*M, US*M PR*M
S*M

R5V R4V R5P R5U R5S

Series 620 63x 64x 665
3
Size NPT 1 ⁄ 4" - ⁄ 4" 1 ⁄ 4" - ⁄ 4" 1 ⁄ 4" - ⁄ 4" 1 ⁄ 4" - 1"
3
3
SAE -4 thru -12 -4 thru -12 -4 thru -12 -4 thru -16
Direct acting X
Pilot operated
Working pressure (bar) 0.3 - 248 0.3 - 248 0.3 - 248 0.3 - 248
R5R R5A (psi) 4 - 3600 4 - 3600 4 - 3600 4 - 3600
Body material
Aluminum X X
Brass X
Stainless steel X X
Soft seat X X X X
View Specs View Product PDF
