PLUMBING SPECIALTIES

BD (31-600/31-700) SERIES ANGLED BODY WATER HEATER DRAIN VALVES
All drains are equipped with Conbraco packing seal assuring easy turning
stem and leak proof drain. Various shank lengths available. Meets CSA
requirements.
FEATURES
• All cast bronze bodies
• Max. rated pressure: 200 psig
• Max. rated temperature: 250˚ F
• 31-600: 3/4” MNPT inlet
• 31-700: 1/2” or 3/4” FNPT inlet
• Made in USA

31-600 HANDLE SUFFIX KEY
Male NPT
-04 Aluminum Wheel - Red
-04P Aluminum Wheel - Plain
-13 Slotted Stem
* Not all variations available in all sizes. Contact customer service.

Series Shank Inlet Wt./100
Number Length (in.) (in.) (lbs.)
31-600 5/8" 3/4" MNPT 27.3
31-601 3/4" 3/4" MNPT 36.0
31-602 1" 3/4" MNPT 35.0
31-700 31-604 1-1/4" 3/4" MNPT 43.0
Female NPT 31-606 1-1/2" 3/4" MNPT 49.5
31-607 1-3/4" 3/4" MNPT 48.0
31-608 2 3/4" MNPT 52.0
31-609 2-1/4" 3/4" MNPT 52.0
31-610 2-1/2" 3/4" MNPT 57.2
31-611 2-3/4" 3/4" MNPT 60.0
31-612 3" 3/4" MNPT 66.3
31-700 1/2" FNPT 39.0
31-701 3/4" FNPT 37.0

BD (35-300) SERIES APOLLO INTERNATIONAL BALL VALVE BIBB FAUCET
TM
Features heavy pattern with large opening. Ideal for boiler and water heater
drains, general liquid dispensing and drainage. The new 45° spout design
allows for easier hose connection access.
FEATURES
• Chrome plated finish; sizes 1/2” and 3/4”
• Pressure rating 200 psig liquid
• Maximum temperature 250°F

A Series Size A Inlet Outlet Wt./100
Number (in.) (in.) (in.) (in.) (lbs.)
35-301-03 1/2 1-1/2 1/2 sweat/thrd connector 0.75-11.5 NHR hose 38.4
35-302-03 3/4 1-3/4 3/4 thrd connector 0.75-11.5 NHR hose 44.5
