Double-Deck PCB Terminal Strips 2.5 mm 2
1 736 Series
52

Solder pins in line Solder pins staggered
Pin spacing: 7.62 mm / 0.3 in. Pin spacing: 7.62 mm / 0.3 in.

0.08–2.5 mm 2 28–12 AWG 0.08–2.5 mm 2 28–12 AWG
630 V/6 kV/2 21 A 300 V/10 A 630 V/6 kV/2 21 A 300 V/10 A

<________L ________>
<________L ________> 5,08 7,62 < <___21___>
___>
5,08
___> 7,62 < <___21___>
<____26,5____> <____26,5____>

4 < 4 <
4,1
1,8
> 3,1 4,1 > > 7,62 < > <__ (_15,24_) <__
> 7,62 < > <__ (_15,24_) <__ 1,8 > <____
2,54
__> <
0,7
> 3< > <__ 0,7
> <__
L = (pole no. – 1) x pin spacing + 5.08 mm + 1
mm

Solder pins in line Solder pins staggered by half the pin spacing
1 Voltage rating between adjacent poles:
320 V/4 kV/3 (III)
320 V/4 kV/2 (III)
630 V/4 kV/2 (II)

Pole No. Item No. Pack. Unit Pole No. Item No. Pack. Unit
Double-deck terminal strip, Double-deck terminal strip,
2 solder pins in line, 2 solder pins staggered by half the pin spacing,
orange orange
2 x 2 736-602 133 2 x 2 736-652 133
3 x 2 736-603 84 3 x 2 736-653 84
4 x 2 736-604 63 4 x 2 736-654 63
6 x 2 736-606 35 6 x 2 736-656 35
8 x 2 736-608 28 8 x 2 736-658 28
12 x 2 736-612 14 12 x 2 736-662 14
16 x 2 736-616 14 16 x 2 736-666 14

Please contact factory for other lengths, colors, mixed-color terminal strips, or direct marking.
