Fluoropolymer Tubing A Hose

The table below lists a generally accepted summary of properties that we believe to be reliable. Please note that many of these resins are produced in several varieties
PTFE (Polytetrafluoroethylene) and property characteristics may vary. Therefore, determination of resin is dependent on the application and this table is only meant to serve as a general guideline.
Working Temperature: 500°F (260°C) ETFE Fluoropolymer
Color: Opaque to translucent Properties* ASTM or PTFE FEP PFA High Purity PFA PVDF Tubing
Unit
• Chemically inert MECHANICAL PROPERTIES B
• Lowest coefficient of friction Specific Gravity D792 2.13-2.22 2.12-2.17 2.12-2.17 - 1.76-1.82 1.74
• Superior dielectric strength D3307 - - - 2.14-2.16 - -
• Exceptional heat resistance D638 200-450 250-330 280-400 - 100-800 430
• Self extinguishing Elongation % D3307 - - - 370 - -
• Non-wetting
• Excellent flexlife Tensile Strength (psi) D638(psi) 2000-7000 2800-4000 4000-5000 - 2000-5000 6962
• Laser markable D3307(psi) - - - 4693 - -
Flexural Strength (psi) D790 no break no break no break no break 1500-5000 5500
Compressive Strength (psi) D695 700-900 725-2200 725-810 na 2000-6000 2500 Coiled Air Hose
PFA (Perfluoroalkoxy) Tensile Elastic Modulus D638 57,000 50,000 72,500- 35,000-220,000 116,030 & Fittings
Working Temperature: 500°F (260°C) (Young's Modulus) (psi) - - 87,000 na
Color: Clear with light blue or tint D790(psi) 71,000-85,000 78,000-92,000 94,000-99,000 - 90,000-168,000 130,534 C
Flexural Modulus D790 103MPa 0.5-0.6 0.5-0.6 0.6-0.7 647-686 280,00-110,000 -
(103kgf/cm2) (5.0-6.0) (5.5-6.4) (6.6-7.0) - -
• High purity resins available
• Low permeation resins available Flex Life (MIT cycles) D2176 >1,000,000 5,000-80,000 10,000-500,000 2000 x 10 3 na na
• Use when you need the temperature range of PTFE
and the clarity of FEP Hardness Durometer Shore D D2240 D50-65 D55 D55-D60 D60 D55-D75 D67
• Exceptional heat resistance Coefficient of Friction (on steel) 0.02 0.05 0.04-0.06 0.05 0.33-0.49 0.20
• Self extinguishing Abrasion Resistance 1000 cycles Taber 8-90 14-20 0.00-96.75 na 16-33 0.005
• Non-wetting
• Good flexlife Impact Strength IZO.D. 73°F (23°C) D256 3 no break no break no break 4 no break Transportation
notched ft/lbs/in
THERMAL PROPERTIES
Melting Point °C 327 260 305 305 125 260 D
FEP (Fluorinated Ethylene Propylene) °F 621 500 582 582 257 500
Working Temperature: 400°F (204°C) Upper Service °C 260 204 260 260 130 180
Color: Clear Temperature(20000h) °F 500 400 500 500 265 356
Flammability UL 94 V-0 V-0 V-0 V-0 V-0 V-0
• Excellent chemical resistance Thermal Conductivity BTU-in/hr-ft 2 , ºF 1.7-2.08 1.4 1.3 na 1.00-1.25 1.65
• Non-wetting Thermal Conductivity Cal-cm/sec-cm 2 , ºC 6 x 10-4 6 x 10-4 6 x 10-6 na na 5.7 x 10-4
• Weldable Linear Coefficient of Thermal D696 55.6 46.1-58.3 66.7 na 7.00-10.8 9.4 (10 -5/ °C)
• Tubes can be sealed by melting Expansion Min/inºF 73.4-140ºF
• Long continuous lengths Heat of Fusion BTU/LB 29-37 4-35 13 na 0.28-0.36 20 Fittings
• Low refractive index Heat of Combustion BTU/LB °F 2200 2200 2300 na na 8100
• Improved clarity over PFA E
• Lower cost alternative to PFA Low Temperature Embrittlement °C -268 -268 -268 -268 -62 -76
°F -450 -450 -450 -450 -80 -105
ELECTRICAL PROPERTIES
D150/10 3 Hz 2.1 2.1 2.1 2.1 3.5
Dielectric Constant 6 2.6
PVDF (Polyvinylidene Fluoride) D150/10 Hz 2.1 2.1 2.1 2.1 10.6
500
508
500
Working Temperature: 265°F (130°C) Dielectric Strength D149/125 MIL >1400 >610 >1400 500 - 600 0.8 na
D149/10 MIL
na
1.5
Color: Varies Volume Resistivity D257/ohm-cm >10 18 >10 18 >10 18 na 2 x 10 14 10 17
Surface Resistivity D257/ohm-cm >10 18 >10 17 >10 17 na 5 x 10 14 >10 15
• Very good chemical resistance GENERAL PROPERTIES
• Excellent resistance to creep and fatigue Tooling, Equipment
• UV Resistant Chemical/Solvent Resistance D543 Excellent Excellent Excellent Excellent Very Good Excellent & Accessories
• Weldable Refractive Index 1.35 1.338 1.34 1.34 1.42 1.447
• Exceptional corrosion resistance for chlorine, Limiting Oxygen Index, % D2868 >95 >95 >95 na 42/75 2 31
fluorine, or bromine environments
Water Contact Angle Angle to Level 110 114 115 na 92 na F
Water Absorption 24h,% D570 <0.01 <0.01 <0.03 <0.01 0.03-0.05 0.03
Weatherability Excellent Excellent Excellent Excellent Excellent Excellent
*General resin properties; Tubing properties may vary.
Tubing Pressure Ranges
Tubing pressures vary by material, tubing size and wall thickness. Please contact Customer Service for specific pressures. General Technical

For detailed ordering information, please consult price list or contact Parflex Division. G
