A PTFE Spiral Cut Cable Wrap

Series: TSWTF

Features

ƒ Provides harnessing for wires and cable while allowing leads at
various points
Tubing Fluoropolymer ƒ Exceptional heat resistance
ƒ Self extinguishing
ƒ Flexible
B ƒ Superior dielectric strength

Certifications
ƒ A-A-59602
ƒ AMS 3653E
Coiled Air Hose & Fittings Applications/Markets ƒ ASTM D3295
ƒ VW1, UL-83 (natural)

C ƒ Cable harnessing Notes
ƒ Wiring closets
ƒ Aerospace
ƒ Automotive ƒ Available in left- or right-hand cut. Please specify with proper
suffix at end of part number (i.e. TSWTF-18-NT-R)
ƒ Working Temperature: 500°F (260°C)
ƒ 100 ft. is the minimum item quantity sold
Transportation ƒ Stock packaging for sizes 1/8" to 1/2" is 100- and 500-ft. non-
continuous spools and, for sizes greater than 1/2",
100-ft. non-continuous spools
D ƒ Custom packaging, sizes and colors are available upon request
Order Information ƒ Spiral cut cable wrap is also quoted in FEP upon request
ƒ Package quantities are not continuous
Example: TSWTF-3/8-5T ƒ Colors available as custom run,
see color code table
TSWTF-3/8-5T – Spiral Wrap
TSWTF-3/8-5T – Material (PTFE)
Fittings TSWTF-3/8-5T – O.D. in inches (.375") Colors
E TSWTF-3/8-5T – Green
TSWTF-3/8-5T – Bulk Tubing ƒ Natural, Translucent
ƒ Colors available as custom run, see color code table

Color Code
N 0 Natural 5 6 Green
Black
Blue
Tooling, Equipment & Accessories 1 2 3 Orange 7 8 9 White
Brown
Violet
Gray
Red
F 4 Yellow

General Technical

G For detailed ordering information, please consult price list or contact Parflex Division.
