polyflex ®
Catalog 4900
Accessories Bend Restrictors, Lubricant, Burst Shield

Support Grips Bend Restrictors

Part No. Description Part No. Description

MK022-03-038 For Hose O.D. 0.63" - 0.74"
MK022-03-039 For Hose O.D. 0.75" - 0.99" MBR003 Molded Vinyl 0.25" I.D.
MK022-03-041 For Hose O.D. 1.00" - 1.24" MBR007 Molded Vinyl 0.41" I.D.
MK022-03-042 For Hose O.D. 1.25" - 1.49" MBR008 Molded Vinyl 0.50" I.D.
MK022-03-043 For Hose O.D. 1.50" - 1.74" MBR009 Molded Vinyl 0.562" I.D.
MK022-03-045 For Hose O.D. 2.25" - 2.49"
MBR010 Molded Vinyl 0.625" I.D.
MBR012 Molded Vinyl 0.77" I.D.
MBR013-B Molded Plastic for 2840D-03V32 hose E
MBR2104 Molded Vinyl for 2244N-025V00 hose
HG8X-04 Molded Plastic for 2380N-4Vxx hose

ThreadMate™ Pressure Safety Shield

Anti-Gall Lubricant

Part No. Description Part No. Description

MTM04T 4-oz Tube
* MHBS012 3/4" I.D. Rubber Safety Shield
612-400-14 Pressure Safety Shield Retaining Sleeve
• ThreadMate is an extreme duty lubricant developed to reduce Pressure Safety Shield Stiffener HP Tube Fitting
galling during the assembly of threaded parts. M55STIF4
M55STIF6 Pressure Safety Shield Stiffener Type "M" Fitting
• ThreadMate promotes reliable sealing of pipe threads even at
high pressure by reducing friction and galling during tightening, * Designated for the 2740D-03V30 and the 2840D-03V34 Hoses.
resulting in higher contact pressures of the sealing surfaces, and
better metal-to-metal contact. ** MHBS016 1" I.D. Pressure Safety Shield
• ThreadMate reduces the torque needed to make pressure tight 416-400-16 Pressure Safety Shield Sleeve
connections and tighten fasteners. ** Designated for the 2740D-05V32 and the 2840D-05V32 Hoses.

E3 Parker Hannifin Corporation
Parflex Division polyflex Operations
®
FluidConnectors
