Page 58 - Parker - Bodies and Cavities

Catalog HY15-3502/US Special Bodies and Cavities
Technical Information 3A, 3-Way

CV
For additional information see Technical Tips on pages BC1-BC6.

Dimensions Check Valves
Millimeters (Inches) 72.85 (2.868) min
62.30 (2.453) max SH
Ø 0.025
45.85 (1.805) min (0.001) A
36.30 (1.429) max
Ø 24.00 (0.945) Shuttle Valves
18.85 (0.742) min Pilot Drill
Ø 0.10 A
(0.004) 3.45
(0.136) LM
Ø 0.13 A 45° A
(0.005)
(3) (2) (1) Load/Motor Controls
Ø 45.00 ± 0.40 1-3/16" - 12 FC
(1.772 ± 0.016 ) UNF-2B
63 63
Flow Controls
+0.05
15° Ø 25.00 –0.00
63 60° 63 60°
+0.002
63 (0.984) –0.000
Ø 32.40 ± 0.10 0.50 (0.020) +0.05 PC
(1.276 ± 0.004 ) Ø 27.00 –0.00
+0.002
19.00 min (1.063) –0.000
(0.748)
36.50 (1.437) R 0.10 +0.15 -0.00 Pressure Controls
(0.004 +0.006 -0.000 )
62.55 (2.463)
0.05 Typical
(0.002) A 79.50 ± 0.40
(3.130 ± 0.016 ) LE
81.00 (3.189) min
Logic Elements
15.00
Cavity
(0.591)
DC
27.40
(1.079) Directional
54.50 Controls
(2.146) (3)
70.00 101.60
(2.756) (4.00) MV
(2)
Manual Valves
2 holes
(1) Ø 10.50 through SV
45.50 (0.413) = =
(1.791)
10.00 65.00 50.80
(0.394) (2.559) (2.00) Solenoid Valves
84.12
(3.312)
PV
Ordering Information Proportional Valves
Cavity Tooling For 3A
LB10 Pilot Drill Ø 24.00 (0.94) CE
Line Port Body Step Drill 8DS31303
Body Size Material Reamer (Alum) 8RM31003A Electronics
Reamer (Steel 8RM31003S Coils &
Code Port Size Code Body Material Counterbore 8CB31100
007 3/4 BSP A Aluminum Tap 8TP31200 BC
066 1 SAE S Steel
Bodies & Cavities
