SERIES AQ

Brass Push-In Fittings

AQ70-P FEMALE ELBOW
Part Number Tube O.D. Female Pipe A B C D
AQ70-P-2X2 1/8 1/8 0.78 0.82 3/8 1.04
AQ70-P-5/32X2 5/32 1/8 0.76 0.82 3/8 1.04
AQ70-P-4X2 1/4 1/8 1.02 0.83 3/8 1.06
AQ70-P-4X4 1/4 1/4 1.13 1.03 1/2 1.31
AQ70-P-6X4 3/8 1/4 1.08 0.98 1/2 1.31

AQ70-PS SWIVEL FEMALE ELBOW
Part Number Tube O.D. Female Pipe A B C D E
AQ70-PS-5/32X2 5/32 1/8 0.73 1.04 3/8 1.22 9/16
AQ70-PS-4X2 1/4 1/8 1.02 1.06 3/8 1.30 9/16
AQ70-PS-4X4 1/4 1/4 0.97 1.25 3/8 1.49 3/4
AQ70-PS-6X4 3/8 1/4 1.08 1.48 1/2 1.80 3/4
AQ70-PS-6X6 * 3/8 3/8 1.10 1.66 1/2 1.99 7/8
AQ70-PS-8X6 * 1/2 3/8 1.25 1.70 5/8 2.09 7/8

AQ71-P MALE RUN TEE

Part Number Tube O.D. Pipe A B C D E
AQ71-P-2X2 * 1/8 1/8 0.73 0.66 5/16 0.66 0.91
AQ71-P-5/32X2 5/32 1/8 0.75 0.67 5/16 0.75 0.95
AQ71-P-3X2 * 3/16 1/8 0.83 0.73 3/8 0.83 1.05
AQ71-P-4X2 1/4 1/8 1.02 0.75 3/8 1.02 1.24
AQ71-P-4X4 1/4 1/4 1.02 0.92 7/16 1.02 1.27
AQ71-P-6X2 * 3/8 1/8 1.02 0.92 1/2 1.02 1.29
AQ71-P-6X4 3/8 1/4 1.08 0.98 1/2 1.08 1.40
AQ71-P-6X6 3/8 3/8 1.08 0.98 1/2 1.08 1.31
AQ71-P-8X6 * 1/2 3/8 1.26 1.05 5/8 1.26 1.55

AQ71-PS SWIVEL MALE RUN TEE
Part Number Tube O.D. Pipe A B C D E
AQ71-PS-2X2 1/8 1/8 0.73 0.73 5/16 0.86 7/16
AQ71-PS-5/32X0 * 5/32 10-32** 0.76 0.76 5/16 0.73 5/16
AQ71-PS-5/32X2 5/32 1/8 0.76 0.76 5/16 0.82 7/16
AQ71-PS-4X2 1/4 1/8 1.02 1.02 3/8 1.01 7/16
AQ71-PS-4X4 1/4 1/4 1.02 1.02 7/16 1.08 9/16
AQ71-PS-6X2 * 3/8 1/8 1.08 1.08 1/2 1.08 7/16
AQ71-PS-6X4 3/8 1/4 1.04 1.04 1/2 1.15 9/16
AQ71-PS-6X6 3/8 3/8 1.06 1.06 1/2 1.17 11/16
AQ71-PS-8X6 * 1/2 3/8 1.24 1.24 5/8 1.28 11/16
AQ71-PS-8X8 1/2 1/2 1.24 1.24 5/8 1.58 7/8
* Made to Order -- consult factory for price and availability. ** Furnished with nylon gasket.
