811 Series Accessories

Jumper bar, I N 63 A, 1000 V, lightgray
2-way 811-472 50 (5x10)
3-way 811-473 40 (4x10)
4-way 811-474 40 (4x10)
5-way 811-475 40 (4x10)
6-way 811-476 30 (3x10)
7-way 811-477 20 (2x10)
8-way 811-478 20 (2x10)
Inserting a fuse. Remove terminal block from the carrier rail. 9-way 811-479 20 (2x10)
10-way 811-480 20 (2x10)
11-way 811-481 20 (2x10)
12-way 811-482 20 (2x10)
Supply module, 35 mm²,
600 VAC, 1000 VDC
811-471 16 (4x4)
Test plug,
with 500 mm cable,
2 mm Ø
red 210-136 50
Coupling kit for 12 poles

811-612 1
Marker carrier,
uses 2009-110 marker strip,
10.4 mm wide
gray 285-442 25
Marking strip, plain,
WMB marking location for convenient identification. Marking adapter (285-442) allows the continuous mark- 11 mm wide,
ing strip to be used. 50 m roll
white 2009-110 1
WMB Multi marking system,
10 strips with 10 markers per card,
stretchable 5 - 5.2 mm
plain 793-5501 5
Screwless end stop, for DIN 35 rail,
gray
6 mm wide 249-116 100 (4x25)
10 mm wide 249-117 50 (2x25)
Twin ferrules for 811 Series, insulated, L1 = 12 mm,
sleeve for 2 x 2.5 mm² / AWG 14
blue 216-545 100
sleeve for 2 x 4 mm² / AWG 12
gray 216-546 100
Jumper bar for quick and convenient commoning. Coupling kit used to create a 2- or 3-pole fuse terminal sleeve for 2 x 6 mm² / AWG 10
block. yellow 216-547 100
